5. 8 SA FE TY VALVE

The steam safety valve is made to open at
the pressure of 3 bar.
WHEN TO REPLACE
For safety reasons each time the valve
comes into operation it should be replaced
to ensure perfect operation.
So if the heater floods or there is excess
steam it is necessary to secure the machine
by replacing the entire valve.
05
HOW TO REPLACE
To replace the safety valve proceed as it
follows.
Utilizing a 17 mm wrench, remove the
1
safety valve pipe from the boiler.
2 Utilizing a 17 mm wrench and a 14 mm
cup hex wrench, open the safety valve.
