Victoria Arduino Eagle One Prima Service Manual page 171

11 .2 TW ELVE (1 2 ) MO N T H S OR 1 0 0 0 0 0 C Y C L ES M A I NT ENA NC E
Approximate time for service is 2 hours uninterrupted. Consider that the technicians per-
forming the service are aware of safety measures before commencing in regards to iso-
lating power, pressure of steam and pressure of water.
Information should be sought from the site manger for any problems or concerns before
commencing work, and to allow sufficient time to complete the task uninterrupted.
Remove all covers before commencing and check for damage/signs of leaks.
Check, adjust, replace (if necessary):
Check for any signs of leaking
in machine
Check for any damaged wires
or caballing
Check for noisy pump motor
Check for blockage in waste hose
Check for leaking from hot water pipe
Check the safety valve
Check the auto-fill function
Check the steam pressure
(_______Bar)
Check the static water pressure
(_______Bar)
Check pump pressure (_______Bar)
Check for over all coffee product
outcomes
Check boiler level
Check for any signs of valves leaking
The water hardness must be less than 6° fr (French degree). The chlorine content
must not exceed 100 mg per litre (0.00000361 lb/cu in), otherwise the conditions
of guarantee of the machine will expire.
Necessary Spare parts
1 X 02280050
•
1 X 03000066.R
•
1 X 01000023
•
1 X 02280012
•
1 X 05000660
•
1 X 02280036
•
1 X 98120001
•
0,5m X 11740003
•
1 X 98110001
•
1 X 02600006
•
1 X 07300872
•
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
M A M M A A I I N N N T E T T E E N A N N A A N N N C C E E E
NOTE
DATA
SITE NAME
TECHNICIAN
TECHNICIAN SIGNATURE
DATE
C C C C C H H H H E E C C C C C K K K K K L L L L IS S S S T T T T
Check and inspect touch screen,
ensuring it is not faulty
Check for boiler leaks
Check the cleaning cycle counts
Total ___________ (if present)
Replace cup gaskets (02280050)
Replace shower screens (03000066.R)
Replace anti vacuum Valve (01000023)
Replace pre-infusion chamber gasket
(02280012)
Replace steam arm o-rings (02280036)
Replace steam arm protectors
(05000660)
Replace the Neplax Valve (98120001)
Replace the Teflon pipe (11740003)
Replace the check valves (98110001)
Replace the o-ring gasket (02600006)
Replace the compass joint
steam-water wand (07300872)
11
171
