Victoria Arduino Eagle One Prima Service Manual page 195

CODE
0 0 0000011
00000113
00000165
00000167
00000175
00000195
00000238
00300005
01000072
01300028
02280012
04100042
03003962
03003966
04100043
04100058
04100078
04100079
04100080
04500060
04500062
05000015
05000420
05000422
05000670
05000672
07300099
07300121
07300249
07300362
07300530
07300534
07300715
07300716
07300786
07300788
09100012
09200022
09200024
11740001
98031268
1 1 1 1 1 1 1 1 1 1 1 1 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
S S P P P A R A A R R E E E P P P A A A R R R T T S S
DESCRIPTION
S/S KNURLED WASHER M4 UNI8842/A
S/S CROSS HEAD CAP SCREW M4x6 7985
S/S SCREW M3x8 TCEI ISO 4762
S/S SCREW M3x12 TCEI ISO 4762
S/S CROSS HEAD CAP SCREW M4X10
S/S SELF TAPPING SCREW 3,9X9,5 TC/TCR
STAINLESS STEEL SCREW M5x12 TCEI
BRASS NUT 1/8 GAS D4 ADD 22.07.96 CH13
ANTI-VIBRATING AD 10X10 M4 MM
PUMP GA072
GASKET O RING 2093 D.27 EP851
2WAY SOLENOID 1/8-1/8 220-230V50/60Hz F2 CE
PUMP SUPPORT BRACKET
MANOMETER SUPPORT BRACKET
2WAY SOLENOID 1/8-1/8 110-120V 60Hz F2 UL TH1xM4
2WAY SOLENOID 1/8-1/8 208-240V 60Hz F2 UL TH2xM3
SOLENOID VALVE 2WAYS 3/4-JG 230V 50/60Hz
SOLENOID VALVE 2 WAYS 3/4-JG115V 60Hz UL
SOLENOID VALVE 2 WAYS 3/4-JG6 UL 208/240V60Hz
MOTOR 115V
MOTOR 230V
TUBE FASTENING WES 6R 1/8
TRAY PLUG UNDER PLATE VA388
DRIP TRAY UNDER PLATED VA388
LOWER EXHAUST MANIFOLD
UPPER EXHAUST MANIFOLD
FITTING ADAPTER 3/8-1/4 ES. 20 ADD. 29.05.96
FITTING L 1/4 M-M CYLINDER ADD. 18.02.97
FITTING 1/8M L = 12 3/8F
STRAIGHT FITTING 1/4 M-FITTINGS.6 340
FITTING L 1/8 F A CALZ. 347 6
RAPID FITTING L D6 - D6
T FITTING 1/8 M -FITTINGS.6 -FITTINGS.6
T FITTING 1/4 M -FITTINGS.6 -FITTINGS.6
PUMPING REGISTER KNOB
STAINLESS STEEL BUSH 7,5x5,1 H5mm
GAUGE SCALE 0-4 BAR 1/8 D.40 VA
PRESSURE TRANSDUCER 0-4 BAR 3/8
PRESSURE TRANSDUCER 0-16 BAR 1/4
TEFLON PIPE 6/4
PRESSURE SENSOR HOSE
END VALIDITY
