Lower side, "low voltage":
Temperature probes, see details below.
1
Presence sensors, see details below.
2
Pressure transducers, see details below.
3
none.
CN16
none.
CN17
DIP switch: all to OFF, used only by the
SW1
manufacturer.
In details, regarding to temperature probes:
coffee boiler temperature probe.
CN9
coffee group temperature probe.
CN10
Easycream temperature probe
CN11
(only with the Easycream optional).
08
In details, regarding to presence sensors:
CN12
filter holder presence sensor.
water tank presence sensor.
CN13
In details, regarding to pressure transduc-
ers:
CN14
water pressure transducer.
CN15
steam boiler pressure transducer.
126
09
09
10 10
11 11
12
12
