Using a 3 mm Allen Key, loosen the three
4
screws to disassemble the panel.
NOTE
There is a washer between the screw
and the panel.
3 .5 R EMO VA L O F T H E L OWE R
F RO N T PAN E L
To remove the lower front panel, it is
necessary to:
1
Remove the cup holder surface and both
side panels .
Remove the work surface pulling out the
2
drip tray.
