1 3 .4 B OIL E R DIAGRA M
13
NO. Q.TY
1 1
1
2
1
3
1
4
2
5
1
6
3
186
PROJECT DATA FOR DIRECTIVE PED 97/23/CE
VOLUMES
TS
P.V.S.
PT
FLUID
PART NUMBER
98031201
98031201
98031201
00080750
00080800
00081410
DESCRIPTION
Lower flange
Boiler body
Upper flange
M6x25 Captive screw
M3x8 Captive screw
M6x20 Captive screw
1,5 l
139°C
2.5 Bar
4 Bar
H2O
MATERIAL
INOX AISI 316L
INOX AISI 316L
INOX
INOX
INOX
