Victoria Arduino Eagle One Prima Service Manual page 181

POSITION
1 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1 1 1 1 1 1 1 1 1 1 1 1 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
D D D IA A A G G G R A R R A A M S M M S S
DESCRIPTION
Water tank
Water tank electrovalve
Pump 10 bar - 70 l/h - 170 W
Water mains inlet
Check valve
Water mains inlet electrovalve
Flowmeter
Calibrated orifice
Coffee boiler 0.14 l - 600 W
Pouring group electrovalve
Filter holder outlet
Discharge outlet
Safety valve 16,5 bar
Anti-vacuum valve
Safety valve 3 bar
Steam boiler 1,5 l - 1600 W
Water level electrovalve
Steam electrovalve
Water inlet electrovalve
Steam wand outlet
Hot water outlet
