Victoria Arduino Eagle One Prima Service Manual page 185

POSITION
1 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
1 1 1 1 1 1 1 1 1 1 1 1 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
D D D IA A A G G G R A R R A A M S M M S S
DESCRIPTION
Steam boiler heating element (1600 W)
Steam boiler temperature probe
Compressor
LED strip
Left LED spotlight
Right LED spotlight
Volumetric counter
Filter holder presence sensor
Water tank presence sensor
Control unit
Keyboard flat
Hot water pressure transducer
Steam boiler pressure transducer
Pouring group temperature probe
Easycream temperature probe
Pouring group heating element (300 W)
Coffee boiler heating element (600 W)
Coffee boiler temperature probe
AC/DC Transformer
Relay
Relay switch
Power relay
Master switch
Pump motor
Tank solenoid valve
Water stop solenoid valve
Air solenoid valve
Steam solenoid valve
Level solenoid valve
Steam / Hot water solenoid valve
Steam / Hot water solenoid valve
Pouring group solenoid valve
Temperature switch
110 V single phase power IN
Steam knob connector (CN2)
Hot water knob connector (CN3)
Keyboard and ghost display
Pressure switch
Thermo-fuse
Remote control module
