Utilizing a Philips screwdriver, remove the
6
head screw.
04
Place a cloth or absorbent paper under-
7
neath the valve and, utilising a 3 mm Al-
len key, remove the two screws that fix
the body to the group.
8 Remove the body of the valve.
Check the contact points that often can
be full of limescale.
Clean utilising an adequately pointed
tool.
Utilizing a vise and a 24 mm wrench, un-
9
screw the valve base and check for the
presence of limescale or oily residues.
These residues could obstruct the free
circulation of the water to the third outlet,
thereby by favouring stagnation of the
water in the filter holder.
In case of oily residues, properly instruct
the staff using the machine to perform
a regular, deep cleaning with suitable
detergents.
58
