4 . 5.1 R EM O VA L OF
TH E TE M P E R A TU RE P ROB E
To remove the temperature probe it's nec-
essary to:
1 Remove the group cover, as described in
Chapter 3.
04
Disconnect the temperature probe from
2
the central unit.
Utilizing a Philips screwdriver from the
3
right side, remove the screw holding the
probe to the group.
54
