Victoria Arduino Eagle One Prima Service Manual page 207

CODE
0 0 4000023
04000126
04000244
04000468
04000470
04001128
04001130
04001131
04001144
04001156
04001161
04001170
04001172
04001174
04200007
04200009
04200096
04200112
04901132
04901521
04901522
1 1 1 1 1 1 1 1 1 1 1 1 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
S S P P P A R A A R R E E E P P P A A A R R R T T S S
DESCRIPTION
SUPPLY CABLE UL AWG3X16 USA PLUG SHEATH 90°C 30
ELECTRIC CABLE 2MT CE SCHUKO PLUG 90° 3X1,5
3POLE CONN CABLE RAST 2.5 / MOLEX L = 800mm
TRANSFORMER 24VDC 50W OPTIONAL
12VDC LED SPOT AURELIA WAVE
WIRING 115 HIGH VOLTAGE
WIRING 230 HIGH VOLTAGE
WIRING LOW VOLTAGE
SUPPLYING WIRING EASY CREAM 1GR.
CSA THERMAL DISJUNCER
LED STRIP 1GR EAGLE ONE
PRESENCE TANK SENSOR
CONN. CABLE TANK SENSOR-CONTROL UNIT
WI-FI MODULE CABLE-CONTROL UNIT
POWER RELAY 30A 230V BIPOLAR
POWER RELAY 30A 115V BIPOLAR
STATIC RELAY 25A 250V 1OUT
RED LIGHT 0/1 BIPOLAR SWITCH UL 16A
WI-FI MODULE
CONTROL UNIT EAGLE ONE 1GR. USA/CAN - AUS/NZ
CONTROL UNIT
