Victoria Arduino Eagle One Prima Service Manual page 197

CODE
0 0 0300002
00300005
00300026
02280036
02280047
02600006
04100024
04100026
04100076
04100077
04100081
04100082
05000660
07300001
07300012
07300069
07300091
07300138
07300147
07300453
07300466
07300720
07300870
07300872
07300876
08000003
08000112
11600004
11740003
75006038.1
75006121
82007003
98007030
98031274
98031276
98031278
98031280
1 1 1 1 1 1 1 1 1 1 1 1 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
S S P P P A R A A R R E E E P P A P A A R R R T T S S
DESCRIPTION
BRASS NUT 1/4 D3 CH18
BRASS NUT 1/8 GAS D4 ADD 22.07.96 CH13
CONICAL TAP 1/4 GAS
O RING STEAM WAND NOZZLE D6x1.2 EPDM70
GASKET OR 17,86x2,62 NBR
TEFLON GASKET FOR STEAM LANCE BALL
3 WAYS SOLENOID 1/4 REGULATOR 90° 230V50/60Hz F3 CE
2 WAYS SOLENOID 1/4 REGULATOR 90° 115V 60Hz EPDM F3UL
SOLENOID VALVE 3 WAYS 1/8-1/8 220-230V 50/60Hz VITON
SOLENOID VALVE 3 WAYS 1/8-1/8 115V 60Hz VITON F2,5 U
SOL. VALVE 2 WAYS 1/8-1/8 100/120V 50/60HZ VITON F1.2
SOL. VALVE 2 WAYS 1/8-1/8 220-230V 50/60HZ VITON F1.2
RUBBER PROTECTION STEAM WAND D10 EAGLE ONE
L FITTING 1/8 M-M 459
FITTING 1/4 1/4M-1/4M Aisi316
1/8" M 1/4" F FITTING ADD. 02.03.88
T FITTING MFM 1/4 CYLINDER
FITTING ADAPTER 1/4M-1/8F ES.17 OT-58
FITTING 1/4 F.7 1/8 F.5 M-M (Update 18.06.97)
T FITTING 1/8 M-M-M
S/S THREADED CONNECTION FOR STEAM WAND
L FITTING 1/4 M - FITTINGS
FITTING 3/8 STEAM-WATER ARTICULATED WAND
COMPASS JOINT STEAM-WATER WAND
STEAM-WATER WAND FIXING RING
HOSE CLAMP D9,1
SPRING FOR ARTICULATED WAND
SILICONE PIPE 5x9 60Sh PEROX
CALIBRATED TEFLON PIPE 6/4
STEAM NOZZLE M8,65X0,75 F1,2 ESAG.1,2
COLD STEAM WAND KIT
HOT WATER DIFFUSER D23,5 F1/8
S/S HOT WATER WAND KIT EAGLE ONE W/ DIFFUSER
BOILER PIPE - HOT WATER SOLENOID VALVE
HOT WATER WAND PIPE
BOILER PIPE - STEAM SOLENOID VALVE
STEAM SOLENOID-STEAM WAND PIPE
END VALIDITY
