Victoria Arduino Eagle One Prima Service Manual page 193

CODE
0 0 0000048
00000089
00000113
00000118
00000160
00000168
00000197
00300021
00300024
01000184
02280012
02280032
02280033
03000004.1
03000066.R
03000072
03000073
03000107
03000460
03000461
04000332
04100017
04100018
04900991
05000842.NO
06200081.2
07300166
07300183.I
07300595
07300613
07300647
07300864
08000017
08000094
09500024
09500026
14100057
14100066
98011002
980400000007100001
980400000007100002
98050028
98050091.PN
98050092.PN
98160000002090
KRIC0001
1 1 1 1 1 1 1 1 1 1 1 1 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
S S P P P A R A A R R E E E P P A P A A R R R T T S S
DESCRIPTION
SELF-TAPPING SCREW 2.9x4.5 TC/T.CR.
S/S CROSS HEAD CAP SCREW M4x12 DIN7985
S/S CROSS HEAD CAP SCREW M4x6 7985
S/S HEX SOCKET CAP SCREW M4x12 5931
S/S WASHER D4X12 UNI 6593
S/S HEXAGON SOCKET HEAD SCREW M6x35 UNI 5931
S/S HEX SOCKET CAP SCREW M6x8 ISO 4762
S/S SLT COUNTERSUNK SCREW M6X18 DIN963
S/S GRUB SCREW M4X16 5923
ADONIS GROUP INSULATOR
GASKET O RING 2093 D.27 EP851
GASKET O RING 114 D15 EP 851
GASKET O RING 75,92x1,78 NBR XP70
DOUBLE BRACKET FOR THERMOSTAT
S/S SHOWER REINFORCED
FILTER ONE COFFEE HIGH 7gr
FILTER TWO COFFEE HIGH 14gr
BLIND FILTER
COFFEE FILTER 20gr (RIDGE-LESS)
COFFEE FILTER 18gr (RIDGE-LESS)
EXT L=85 + FASTON F-F A FLAG AWG18
3WAY SOLENOID DIS BASE 1/8 220-230V 50/60Hz CE
3WAY SOLENOID DIS BASE 1/8110-120V60Hz F1.6 UL
GROUP TEMPERATURE PROBE PT1000
FILTER HOLDER KNOB LOCK 2003 PAINTED MATT BLACK
GR RING OR CHROME OT-58 - FILTER HOLDER SENSOR
FLANGE BLOCK LOCK SOLENOID HOLDER
GROUP DIFFUSER h=3 S/S Aisi316
FILTER HOLDER KNOB INSERT 2003 AVP ZINC.
PRE INFUSION CHAMBER INSERT GROUP
S/S WASHER FILTER HOLDER KNOB DIFFUSER
FITTING 1/4M 1/8M + THREADED M6 Aisi316 +
S/S FILTER LOCKING SPRING
INSULATION SHEET SPRING DELIVERY GROUP
MANUAL THERMOSTAT 135°C TRIP FREE GREEN DRIPPI
AUTOMATIC THERMOSTAT 110°C
HEATING ELEMENT D10x115 300W 115V
CARTRIDGE HEAT. ELEMENT D10x115 300W 230V
ANODISED COFFEE TAMPER BRILLIANT WHITE
DISPENSING GROUP SET 1 GROUP CE
DISPENSING GROUP SET 1 GROUP CSA
BLACK LEATHER FILTER HOLDER HANDLE
1 WAY FILTER HOLDER IN BLACK LEATHER W/OUT FILTER
2 WAYS FILTER HOLDER IN BLACK LEATHER W/OUT FILTER
FILTER HOLDER PRESENCE SENSOR W/CONNECTORS
6 x PK LONGLIFE CONICA GASKET SHEATH AURELIA-VA
END VALIDITY
14
193
