Front Panel; Opening The Front Panel - HP Visualize c3700 Owner's Manual

Changing Your Workstation's Hardware Configuration

Front Panel

Front Panel
This section explains how to open and close the workstation's front panel.

Opening the Front Panel

Perform the following steps to open the workstation.
1. Power off the workstation, and unplug the workstation's power cord
from the electrical outlet. Note that when you press the workstation's
power switch, the workstation automatically performs a shutdown
-q.
2. Attach the static-grounding wrist strap by following the instructions
on the package. Attach the sticky end of the wrist strap to bare metal
on the back panel of the workstation.
3. Unlatch the front panel (also known as the front bezel) by pressing in
on the two latch buttons located on the right side of the front panel.
See Figure 4-1. If the front panel does not open, you may have to
locate the front panel key and unlock it.
76 Chapter 4
