Changing Your Workstation's Hardware Configuration
Hard Disk Drives
Figure 4-36 The Hard Drive Slots
PCI
Slots
(4)
Power
Supply
2. Loosen the captive T-15 Torx thumbscrew securing the disk drive tray
118
to the system board. As you grasp the tray and slide to the front of the
workstation, the tray will unseat from the chassis rail. See Figure
4-37. You may need to angle the disk drive tray slightly to disengage
the hooks as you slide it along the rail.
Memory slots (4)
SCSI ID 6
SCSI ID 5
Chapter 4
