HP Visualize c3700 Owner's Manual page 26

Overview
Product Information
HP USB Three Button Mouse
For general information on the various cursor shapes associated with
different areas of HP CDE while using a mouse, see the Using Your HP
Workstation manual.
LAN Connector
Your workstation has one built-in, Ethernet IEEE 802.3, RJ45 Twisted
Pair (TP) connector for 802.3 (Ethernet) or 10/100 BaseT networking.
Your workstation will automatically select the correct network setting.
Parallel Connector
The 25-pin HP Parallel I/O interface uses IEEE 1284 I/O interface
protocols to support peripheral devices such as printers and plotters.
consult the documentation that accompanies each parallel peripheral
device for specific information concerning its use.
Audio Connectors
Your workstation has audio-input and -output capability through
external input and output connectors on the rear panel and through an
internal speaker. As shown in Figure 1-4 on the next page, the
workstation's rear panel contains four audio connectors: Line In, Line
Out, Microphone In, and Headphones Out.
Figure 1-4 Audio Connectors
Line In
Line Out
Microphone In
Headphones Out
26 Chapter 1
