NOTE
Changing Your Workstation's Hardware Configuration
I/O Cards
appropriately positioned. See Figure 4-8. If the card is full length, the
non-bulkhead end of the card should be placed in the I/O card guide.
Press firmly and evenly on the I/O card until it is in the connector.
Secure the I/O card to the bulkhead with the T-15 Torx screw.
6. Replace the I/O card retainer by placing the bottom retainer hook in
the slot on the air divider and the clips on the PULL tabs into their
slots on the chassis wall. See Figure 4-7.
7. Close the left side panel of the workstation by following the procedure
in the section "Closing the Left Side Panel" in this chapter.
If you connect a monitor to a graphics card, you will need to change the
console path as described in "Displaying and Setting Paths" on page 161.
86 Chapter 4
