Changing Your Workstation's Hardware Configuration
Removable Media Devices
2. Remove the floppy disk drive bay's rear cover by unscrewing the T-15
Figure 4-23 Removing the Floppy Disk Drive Bay's Rear Cover
102
Torx screw as shown in Figure 4-23. Note that the floppy disk drive
bay's rear cover is located on the rear of the removable media chassis
inside the workstation. Push the cover handle away from the rear of
the removable media chassis approximately one inch. Next pull the
cover handle toward you. The floppy data cable and power cable are
now accessible to you.
Rear Cover Handle
Power
Cable
Rear Cover
Data Cable
T-15
Torx/Slotted
Screw
Chapter 4
