Changing Your Workstation's Hardware Configuration
Removable Media Devices
9. Make sure that the audio, ATAPI and power cables are positioned so
Figure 4-16 Replacing the CD Drive Bay's Rear Cover
10. Remove the plastic CD drive blank from the workstation's front
11. Complete the installation of the CD drive by replacing the front and
12. Verify that the CD drive is recognized by the system. See the section
94
that they come out of the bottom edge of the CD drive bay's rear cover.
This edge is rounded to prevent cutting of the cables. See Figure 4-16.
Next, secure the CD drive bay's rear cover using the T-15 Torx/slotted
screw. The screw should be tightened using 6 inch-pounds of torque.
When you replace the rear cover, the ferrite bead on the ATAPI cable
must remain outside of the CD drive bay's rear cover.
Rear Cover
Ferrite Bead
panel.
side panels of the workstation as explained in the sections "Closing
the Left Side Panel" and "Closing the Front Panel" in this chapter.
You should also make sure that all cables are positioned within the
workstation so that they cannot be damaged.
"Verifying the CD Drive Operation" in Chapter 2, "Using Your CD
Drive."
T-15
Torx/Slotted
Screw
