Rear Panel Components

This section describes the following components on the rear panel of the
B2000 workstation:
• Monitor connector
• Serial (RS-232) connectors
• USB (Universal Serial Bus) connectors
• LAN (Ethernet IEEE 802.3, RJ45 Twisted Pair 10/100 BaseT)
connector
• Parallel (IEEE 1284) connector
• Audio connectors (Line In, Line Out, Microphone In, and Headphones
Out)
• TOC (Transfer Of Control) button
• I/O slots
• Power cord connector
• Security loop
To maintain FCC/EMI compliance, verify that all cables are fully seated
and properly fastened.
