HP Visualize c3700 Owner's Manual page 89

2. Remove the CD drive bay's rear cover by unscrewing the T-15
Figure 4-10 Removing the CD Drive Bay's Rear Cover
Rear Cover Handle
Rear Cover
Audio
Cable
Ferrite Bead
ATAPI Cable
Power Cable
3. Rotate the workstation around until you see the front of the
Figure 4-11 Front of Workstation with the Front Panel Removed
4. Remove both CD drive bracket screws (T-15 Torx/slotted screws) and
Chapter 4
Changing Your Workstation's Hardware Configuration
Torx/slotted screw as shown in Figure 4-10. Note that the CD drive's
rear cover is located on the rear of the removable media chassis inside
the workstation. Push the cover handle away from the rear of the
removable media chassis approximately one inch. Next pull the cover
handle toward you. The audio, ATAPI and power cables are now
accessible to you.
workstation as shown in Figure 4-11.
LCD Display
Power Switch
CD drive
Blank
Floppy Disk
Blank
pull the CD drive bracket out of the chassis assembly as shown in
Removable Media Devices
T-15
Torx/Slotted
Screw
89
