Changing Your Workstation's Hardware Configuration
Removable Media Devices
2. Remove the CD drive bay's rear cover by unscrewing the T-15
Figure 4-17 Removing the CD Drive Bay's Rear Cover
Audio
Cable
Ferrite Bead
ATAPI Cable
96
Torx/slotted screw as shown in Figure 4-17. Note that the CD drive
bay's rear cover is located on the back of the removable media chassis
inside the workstation. Push the cover handle away from the back of
the removable media chassis approximately one inch. Next pull the
cover handle toward you. The audio, ATAPI and power cables are now
accessible to you. Disconnect these cables from the CD drive.
Rear Rear Cover
Cover Handle
Power Cable
T-15
Torx/Slotted
Screw
Chapter 4
