HP Visualize c3700 Owner's Manual page 18

Table 1-1
Overview
Product Information
Key Features of the B2000 Workstation
Feature
Standard Networking
Standard I/O
I/O Expansion Capabilities
Monitors Currently Supported
Graphics
Keyboard
Mouse
18
Description
Ethernet IEEE 802.3, RJ45 Twisted Pair
10/100 BaseT
• Two Serial (RS-232) ports
• Two USB (Universal Serial Bus) ports
• One Parallel (IEEE 1284) port
• Four Audio ports (Line In, Line Out,
Microphone In, and Headphones Out)
Four PCI (Peripheral Connect Interface) slots:
• Two 64-bit PCI-2X slots at 5V, 33 MHz
• Two 32-bit PCI-1X slots at 5V, 33MHz
• 21-inch, 1280 1024 (stereo capable)
color, 75 Hz
• 21-inch, 1600 1200 color, 75 Hz
• 19-inch, 1280 1024 color, 75 Hz
• Integrated HP V
ISUALIZE
on system board
• HP V fxe graphics card (optional)
ISUALIZE
USB (Universal Serial Bus) HP keyboard
USB (Universal Serial Bus) HP 3 button
mouse
fxe graphics chip
Chapter 1
