HP Visualize c3700 Owner's Manual page 79

Figure 4-2
T-15 Torx
Thumbscrew
T-15 Torx
Thumbscrew
NOTE
4. Grasp the back edge of the left side panel and rotate it outward
approximately 30 degrees to the workstation. Next, pull the panel
toward you as shown in Figure 4-2. This releases the panel's top and
bottom left side hook hinges from their hinge slots. See Figure 4-2.
Opening the Left Side Panel
The EMI gasket, as shown in Figure 4-2, must not be removed from the
side panel.
Chapter 4
Changing Your Workstation's Hardware Configuration
Hinge Slot
Left Side Panel
Left Side Panel
Hinge Hook
EMI Gasket
79
