4. Insert the T-15 Torx Hard Disk Mounting Screws through the rubber
Figure 4-40 Inserting the Hard Disk Drive
Hard Disk
Drive Bracket
5. Slide the assembly into its hard drive slot, and push inward firmly
Chapter 4
Changing Your Workstation's Hardware Configuration
mounting grommets and into the screw holes located on the sides of
the hard disk drive. See Figure 4-40.
Hard Disk
Drive
until the front of the hard disk drive bracket is flush with the disk
drive connector on the system board. See Figure 4-41. The bracket
hooks will lock into the chassis rail. The side panel should now be
replaced as described in the section "Closing the Side Panel" in this
chapter.
T-15 Torx Shoulder Screw
Bracket Hooks
(quantity 4)
Hard Disk Drives
Mounting
Grommets
(do not remove)
