HP Visualize c3700 Owner's Manual page 90

Figure 4-12
CAUTION
Changing Your Workstation's Hardware Configuration
Removable Media Devices
Figure 4-12. Next remove the four CD drive blank filler screws (T-15
Torx/slotted screws) as shown in Figure 4-12 and remove the blank
filler from the bracket. You are now ready to mount the CD drive into
the CD drive bracket. Note you will need the blank filler screws to
mount the CD drive.
Removing the CD Drive Bracket and Blank
Blank Filler Screws
(T-15 Torx Screws)
CD drives are susceptible to mechanical and electronic shock. When
handling the drive, always wear the static-grounding wrist strap that
came in the CD drive kit. Always handle the drive carefully.
90
CD drive Bracket
Blank
Bracket Screws
Chapter 4
