Changing Your Workstation's Hardware Configuration
Removable Media Devices
4. Remove both CD drive bracket screws (T-15 Torx/slotted screws) and
Figure 4-19
Removing the CD Drive
98
pull the CD drive out of the chassis assembly as shown in Figure
4-19. Next remove the four CD drive mounting screws (T-15
Torx/slotted screws) as shown in Figure 4-19 and remove the CD
drive from the bracket. You are now ready to attach the CD drive
blank to the CD drive bracket.
Bracket Runner
CD Drive Mounting
Screws (T-15 Torx Screws)
CD Drive Bracket
Bracket Guide
CD Drive
Bracket Screws
(T-15 Torx Screws)
Chapter 4
