HP Visualize c3700 Owner's Manual page 134

Changing Your Workstation's Hardware Configuration
Memory Cards
2. Position the memory slots so they face you as shown in Figure 4-47.
3. Locate the four internal memory slots, and load the DIMM cards in
Figure 4-47 Memory Card Slot Numbers and Loading Sequence
SL0
SL3
SL1
SL2
134
Note that Figure 4-47 also provides the loading sequence for the
DIMM cards. This loading sequence must be maintained when you
install the DIMM cards, but the size of the DIMM card put in each
slot can vary. For example, you can install a 256Mbyte card before a
512Mbyte card and then follow the installation of the 512Mbyte card
with another 256Mbyte card. The B2000 workstations supports 128
Mbyte, 256 Mbyte and 512 Mbyte DIMM cards.
the slots using the loading sequence provided in Figure 4-47. Note
that the label located on the floor of the chassis describes the
installation sequence.
Load 1st
Load 4th
Load 2nd
Load 3rd
Memory Slots
(four slots)
Chapter 4
