Page 15: Overview
Overview This chapter provides an overview of the key features and components of the HP V B2000 workstation. It then explains how to get started ISUALIZE using your B2000 workstation.
Page 16 Overview This chapter contains the following topics: • Product Information — “Key Features” on page 17 — “Front Panel Components” on page 19 — “Rear Panel Components” on page 22 — “Memory” on page 31 — “Monitors” on page 31 •...
Page 17: Product Information
This section describes the key features and the components of the B2000 workstation. The purpose of this section is to familiarize you with your new workstation. Key Features Table 1-1 lists the key features of the HP V Table 1-1 Key Features of the B2000 Workstation Feature...
Page 18 19-inch, 1280 1024 color, 75 Hz • Integrated HP V fxe graphics chip ISUALIZE on system board • HP V fxe graphics card (optional) ISUALIZE USB (Universal Serial Bus) HP keyboard USB (Universal Serial Bus) HP 3 button mouse Chapter 1...
Page 19: Front Panel Components
Front Panel Components Figure 1-1 shows the components that are located on the front panel of the B2000 workstation. The following subsections describe the system LCD, power switch, and the internal storage devices (including the standard CD drive and optional ﬂoppy disk drive) that are located on the front panel.
Page 20 -q command. This prevents any damage to programs and data on your system disk. Pressing the power switch on again automatically boots up the HP-UX operating system, if your system has been conﬁgured to auto boot. For information on setting auto boot, see “Setting the Auto Boot and Auto...
Page 21 Overview Product Information Internal Storage Devices The B2000 workstation has one 9 GB 7200 RPM Ultra2 Wide Low-Voltage Differential (LVD) SCSI hard disk drive as a standard component. Optionally, the workstation also supports a second 9 GB 7200 RPM Ultra2 Wide LVD SCSI hard disk drive. In addition, the B2000 workstation has one ATAPI CD drive as a standard component.
Page 22: Rear Panel Components
Overview Product Information Rear Panel Components This section describes the following components on the rear panel of the B2000 workstation: • Monitor connector • Serial (RS-232) connectors • USB (Universal Serial Bus) connectors • LAN (Ethernet IEEE 802.3, RJ45 Twisted Pair 10/100 BaseT) connector •...
Page 23 Microphone In Headphones Out Monitor Connector The B2000 workstation has an integrated HP V chip on the system board. Thus, the monitor connector on the rear panel of the workstation connects your monitor to this graphics chip on the system board.
Page 24 The SIO ports are programmable, allowing functions such as bit rate, character length, parity, and stop bits to be set. You can set these by using the HP-UX System Administration Manager (SAM) utility, or by selecting a system special device ﬁle with the functions already programmed.
Page 25 The USB connectors located on the rear panel of the workstation provide and interface for the keyboard ad mouse to the system. These USB connectors support only the HP keyboard, HP mouse and USB hub. The keyboard and mouse may be plugged into either USB connector on the rear of the workstation or plugged into the USB hub.
Page 26 Product Information HP USB Three Button Mouse For general information on the various cursor shapes associated with different areas of HP CDE while using a mouse, see the Using Your HP Workstation manual. LAN Connector Your workstation has one built-in, Ethernet IEEE 802.3, RJ45 Twisted Pair (TP) connector for 802.3 (Ethernet) or 10/100 BaseT networking.
Page 27 audio Hewlett-Packard recommends using gold-plated plugs available through audio retailers for best quality recording and playback through the external connectors. The audio electrical speciﬁcations are summarized in Table 1-3. Table 1-3 Audio Electrical Speciﬁcations Frequency Response Input Sensitivity/Impedance: Line in Microphone in Maximum Output Level/Impedance: Line out...
Page 28 Overview Product Information TOC Button You can press the TOC (Transfer Of Control) button on the rear panel to interrupt the system. I/O Slots The four I/O slots located on the rear panel are PCI (Peripheral Connect Interface) slots, which you can use for add-on I/O interface cards. There are two PCI-2X slots and two PCI-1X slots, which are deﬁned as follows: Slot 1: 64-bit PCI-2X at 5V, 33 MHz Slot 2: 64-bit PCI-2X at 5V, 33 MHz...
Page 29 Security Loop There is also a security loop on the rear panel of the B2000 workstation. The security loop allows you to lock the workstation’s left side panel, thus securing the internal components of your workstation. Figure 1-5 provides a view of the security loop. Figure 1-5 Security Loop Components Security Loop Pin...
Page 30 Overview Product Information To lock your workstation’s left side panel, follow these steps: 1. Make sure the workstation’s left side panel is closed. See Figure 1-6. Figure 1-6 Closed Left Side Panel 2. Push the security loop’s pin into the security loop pin hole, and insert the padlock’s latch through the holes at the top and bottom of the security loop.
Page 31: Memory
LCD. If a DIMM error does occur, please refer to the “Memory Failures” section in Chapter 6. Monitors Your HP monitor should be set to one of the following resolutions: • 1280 1024 color (stereo capable), 75Hz, VESA • 1600 1200 color, 75Hz, VESA •...
Page 32: Getting Started
Managing Systems and Workgroups manual to conﬁgure your kernel. If you have any questions about Instant Ignition, refer to the Using Your HP Workstation manual for more information. NOTE You can ﬁnd the documents mentioned in the previous paragraph on HP’s documentation website at the following URL:...
Page 33: Information You Need To Record
Overview Getting Started Information You Need to Record Before you begin using your workstation, take a moment to gather the following important information and record it in the appropriate subsection for future use: • LAN Station ID • IP (Internet Protocol) address •...
Page 34: Gathering Required Information
Overview Getting Started Gathering Required Information The start-up procedure for your workstation will require you to supply the following information. Therefore, you should gather the following information before you power on the workstation for the ﬁrst time. NOTE If you are not the system administrator for your workstation, and you do not know the required information, ask your system administrator for the information.
Page 35: Powering On The Workstation For The First Time
When you have answered these questions, the HP CDE login screen will appear. Once the HP CDE login screen appears, you can log in as root—initially there is no password.
Page 36 When you have ﬁnished answering all of the questions, the workstation completes its start-up sequence and displays the HP CDE login screen. 6. Log into your ﬁrst HP CDE session as root. For information on logging into HP CDE, see the Common Desktop Environment User’s Guide.
Page 37: Documentation
7. After you log into your ﬁrst HP CDE session you can customize the desktop user interface for your speciﬁc language. For detailed information to conﬁgure localized desktop sessions, see the Common Desktop Environment User’s Guide. 8. Use the HP-UX System Administration Manager (SAM) utility to set-up user accounts.
Page 38 Overview Getting Started Chapter 1...
Page 39: Using Your Cd Drive
Using Your CD Drive This chapter provides an overview of the optional CD drive and media as well as an explanation of how to use the CD drive.
Page 40 • Audio Control for the CD Drive • CD Media Description The instructions in this chapter assume you are using the HP-UX 10.20 operating system and Workstation Additional Core Enhancements for HP-UX 10.20 (December 1999) with the HP CDE interface.
Page 41: Cd Media Description
CD Media Description CDs, which can be CD-ROMs, CD-Rs, or CD-RWs, are 120mm (4.7 inches) in diameter, and use one data surface with a capacity of 600 megabytes. The data surface contains pits and ﬂat spots arranged in a continuous spiral track, which is read at a constant speed. You may access ﬁles and data stored on a CD, but you may not write ﬁles or data to a CD.
Page 42: Operating The Cd Drive
Using Your CD Drive Operating the CD Drive Operating the CD Drive This section provides a description of the CD drive and it describes how to perform tasks with your CD drive. CD Drive The CD drive is a mass storage device that can read removable CD-ROM, CD-R, and CD-WR media.
Page 43 Controls and Features Figure 2-1 and Table 2-1 describe the operating controls and features of the CD drive. NOTE The exact positioning of CD Drive controls/features may vary depending on the model of the device. Figure 2-1 CD Drive Controls and Features Disk Tray Busy Indicator...
Page 44 Using Your CD Drive Operating the CD Drive To listen to an audio CD, use the headphone jack on the rear panel, and control the sound volume via software called “xmcd” (for details, see “Audio Control for the CD Drive” on page 56). Chapter 2...
Page 45: Loading And Unloading A Cd
Using Your CD Drive Operating the CD Drive Loading and Unloading a CD This section explains how to load or unload a CD. NOTE To use the ﬁle system on a CD, you must be superuser (root) and mount the disk as discussed in the section “Mounting a CD Using SAM.” Once the CD has been mounted, you must unmount it before removing the CD.
Page 46 Using Your CD Drive Operating the CD Drive 2. Hold the disk by the edges with the label side up and place it in the disk tray as shown in Figure 2-3. Figure 2-3 Placing the CD in the Disk Tray 3.
Page 47: Locating Help
Using Your CD Drive Operating the CD Drive Unloading a CD To unload a disk from the Disk Tray, follow these steps: 1. Press and release the eject button on the CD drive to open the disk tray. 2. Grasp the disk by the edges and lift it out of the disk tray. 3.
Page 48: Mounting And Unmounting A Cd
You must unmount the CD before removing it from the drive. To mount a CD on an HP-UX 10.20 operating system with the Workstation Additional Core Enhancements for HP-UX 10.20 (December 1999), perform the steps covered in this section.
Page 49 3. Double click on the System_Admin icon in the Application Manager window. 4. Double click on the Sam icon in the Application Manager -- System_Admin window. If you are root, the System Application Manager (SAM) will appear on your screen. 5.
Page 50 Using Your CD Drive Mounting and Unmounting a CD 6. Double click on the Disk Devices icon. The following screen message is displayed: Scanning the system’s hardware... The Disk and File Systems window opens containing a list of devices installed in this system. From the list of devices, choose the CD drive you would like to conﬁgure as a ﬁle system by clicking on the device to highlight it.
Page 51: Unmounting A Cd Using Sam
Before you unmount a CD, make sure that your working directory is set to a directory other than the one under which the disk was mounted. To unmount a CD on an HP-UX 10.20 operating system with the Workstation Additional Core Enhancements for HP-UX 10.20 (December 1999), perform the steps covered in this section.
Page 52 Using Your CD Drive Mounting and Unmounting a CD 4. Double click on the Sam icon in the Application Manager -- System_Admin window. If you are root, the System Application Manager (SAM) will appear on your screen. 5. Double click on the Disks and File Systems icon. 6.
Page 53 7. Click on Remove in the Actions menu. In the window that next appears, click on the Yes button. This will unmount the CD. You will need to wait for a short time before the CD is unmounted. The CD is successfully unmounted when you see Unused in the Use column of the Add Disk without LVM window.
Page 54: Verifying The Cd Drive Operation
Using Your CD Drive Verifying the CD Drive Operation Verifying the CD Drive Operation To verify that your workstation can communicate with the CD drive, follow the steps covered in this section. Note that to perform the steps required in this section, you must be superuser (root). If you cannot log in as root contact your system administrator.
Page 55: Conﬁguring The Cd Driver
Conﬁguring the CD Driver If you reload software or rebuild the Instant Ignition system on your workstation, you may need to reconﬁgure the HP-UX kernel to add the CD driver. Use the SAM utility to add the CD driver and build a new HP-UX kernel.
Page 56: Audio Control For The Cd Drive
X window system using the Motif graphical user interface. The xmcd utility is not supported by Hewlett-Packard. Since the xmcd utility is not a part of HP-UX, you will need to download it off the web using your web browser and this URL: http://metalab.unc.edu/tkan/xmcd...
Page 57: Using The Xmcd Utility
Line Input Jack Line Output Jack Microphone Jack Headphone Jack 3. Click on the Audio icon located on your HP CDE control panel. Audio Icon Chapter 2 Using Your CD Drive Audio Control for the CD Drive...
Page 58 Using Your CD Drive Audio Control for the CD Drive 4. Click on the Monitoring checkbox in the Audio window to select it. Then select the Output menu and click on the Headphones item in the menu list. In the File menu select the item Close, this will close the Audio window and save your settings.
Page 59: Using Your 3.5-Inch Floppy Disk Drive
Using Your 3.5-Inch Floppy Disk Drive This chapter describes how to perform tasks that allow you to archive to or transfer data from the 3.5-inch ﬂoppy disk drive.
Page 60 Using Your 3.5-Inch Floppy Disk Drive The instructions in this chapter assume you are using the HP-UX 10.20 operating system and the Workstation Additional Core Enhancements for HP-UX 10.20 (December 1999) with the HP CDE interface. NOTE When examples of user input are given in this chapter, enter them at the command-line prompt in an HP CDE terminal window.
Page 61: Operating The Floppy Drive
Operating the Floppy Drive This section describes how to perform tasks with your 3.5-inch ﬂoppy disk drive. Floppy Disk Drive The ﬂoppy disk drive is a random access read/write mass storage device that uses removable ﬂoppy diskettes. The drive supports the 1.44 Mbyte High Density standard.
Page 62: Using The Floppy Diskette
Using Your 3.5-Inch Floppy Disk Drive Operating the Floppy Drive Using the Floppy Diskette This section describes basic information needed to use your ﬂoppy diskettes. Setting the Write-Protect Tab on a Diskette You can only store or change information on a diskette when the write-protect tab is in the write position.
Page 63: Using Device Files
Using Your 3.5-Inch Floppy Disk Drive Operating the Floppy Drive Inserting and Removing a Diskette Follow these steps to insert and remove a diskette from the ﬂoppy disk drive. 1. Insert the diskette into the drive, as shown in Figure 3-3. Figure 3-3 Inserting and Removing a Floppy Diskette 2.
Page 64 Using Your 3.5-Inch Floppy Disk Drive Operating the Floppy Drive To determine what device ﬁles are available for use with your ﬂoppy drive, use the following procedure: 1. Log in as root. 2. Move the mouse pointer to the Application Manager control for tools and click the left mouse button.
Page 65 4. Double click on the Sam icon in the Application Manager -- System_Admin window. If you are root, the System Application Manager (SAM) will appear on your screen. 5. Double click on the Disks and File Systems icon. 6. Double click on the Disk Devices icon. The following screen message is displayed: Scanning the system’s hardware...
Page 66: Formatting A New Diskette
Using Your 3.5-Inch Floppy Disk Drive Operating the Floppy Drive Formatting a New Diskette If you have ﬂoppy diskettes that have been previously formatted using the mediainit utility, you can skip this section. Otherwise, you must always format a new ﬂoppy diskette with the mediainit utility before using the diskette.
Page 67: Transferring Data To And From A Floppy Diskette
Transferring Data To and From a Floppy Diskette This section describes how to transfer data (reading and writing) to and from your ﬂoppy diskette using the HP-UX tar command with your ﬂoppy drive’s device ﬁle. You need to set the write-protect tab to the write position to transfer data to the diskette.
Page 68: Listing The Files On A Floppy Diskette
Using Your 3.5-Inch Floppy Disk Drive Operating the Floppy Drive Restoring Files from a Floppy Diskette to Your System Use the following instructions to restore ﬁles from a ﬂoppy diskette to your system: 1. Load the ﬂoppy diskette into the disk drive. 2.
Page 69: Verifying The Floppy Drive Conﬁguration
Device driver floppy is not in the kernel If you receive this message, go to the section, “Conﬁguring the Floppy Driver” in this chapter for information on adding the sioflop driver to the HP-UX kernel conﬁguration. Chapter 3 Using Your 3.5-Inch Floppy Disk Drive Verifying the Floppy Drive Conﬁguration...
Page 70: Additional Floppy Drive Information
Conﬁguring the Floppy Driver If you reload software or rebuild the Instant Ignition system on your computer, you may need to reconﬁgure the HP-UX kernel to add the ﬂoppy disk driver. Use the SAM utility to add the sioflop disk driver and build a new HP-UX kernel.
Page 71 For more information on copying to or from DOS ﬁles, refer to the doscp man page by typing the following command in a terminal window at the prompt and pressing Enter man doscp For more information on listing DOS directories, refer to the dosls man page by typing the following command in a terminal window at the prompt and pressing Enter...
Page 72 Using Your 3.5-Inch Floppy Disk Drive Additional Floppy Drive Information Chapter 3...
Page 73: Changing Your Workstation's Hardware Conﬁguration
Changing Your Workstation’s Hardware Conﬁguration This chapter contains the procedures to change the hardware conﬁguration for your HP V B2000 workstation. ISUALIZE...
Page 74 Additional Core Enhancements software bundle (December 1999) with the HP CDE interface. Information for the HP CDE interface can be found in the HP CDE Getting Started Guide. CAUTION Always wear a properly grounded wrist strap when reconﬁguring your workstation with internal devices.
Page 75 ﬂat-bladed screwdrivers. • Needle-nose pliers NOTE Many of the HP-UX commands in this chapter will require that you become superuser (root). If you cannot log in as root, contact your system administrator. Chapter 4...
Page 76: Front Panel
Changing Your Workstation’s Hardware Conﬁguration Front Panel Front Panel This section explains how to open and close the workstation’s front panel. Opening the Front Panel Perform the following steps to open the workstation. 1. Power off the workstation, and unplug the workstation’s power cord from the electrical outlet.
Page 77: Closing The Front Panel
Figure 4-1 Opening the Front Panel 4. Swing the panel outward on its left snap hinges until the panel comes free and place the front panel in a location where it cannot get broken. Closing the Front Panel Perform the following steps to close the workstation. 1.
Page 78: Left Side Panel
Changing Your Workstation’s Hardware Conﬁguration Left Side Panel Left Side Panel This section explains how to open and close the left side panel of the workstation. This side panel will have to be opened whenever you need access to the internal components of the workstation. Opening the Left Side Panel Perform these steps to open the left side panel.
Page 79 4. Grasp the back edge of the left side panel and rotate it outward approximately 30 degrees to the workstation. Next, pull the panel toward you as shown in Figure 4-2. This releases the panel’s top and bottom left side hook hinges from their hinge slots. See Figure 4-2. Figure 4-2 Opening the Left Side Panel T-15 Torx...
Page 80: Closing The Left Side Panel
Changing Your Workstation’s Hardware Conﬁguration Left Side Panel Closing the Left Side Panel Perform these steps to close the left side panel. 1. Hold the left side panel so that the top and bottom hinge hooks can be inserted into their hinge slots. See Figure 4-2. Note that the hinge slots are located on the far right edge of the workstation (using the back of the workstation as the reference).
Page 81: I/O Cards
I/O Cards Your B2000 workstation’s system board has four Peripheral Connect Interface (PCI) slots for option boards. Slots 1 and 2 are full-size PCI slots. Slots 3 and 4 are half-size PCI slots. NOTE The graphics boards supported by your workstation are designed to be electrically compatible with PCI option slots.
Page 82 Changing Your Workstation’s Hardware Conﬁguration I/O Cards Figure 4-4 Location of B2000 System Label CAUTION If you are installing an additional graphics card, you must insert the fx card in Slot 1 for optimal performance. After you connect the monitor to the additional graphics card, you will need to change the graphics path for that monitor.
Page 83: Removing I/O Cards
Figure 4-5 B2000 System Label Note that the four I/O slots as seen from the back of the workstation are labeled from top to bottom starting with one. See Figure 4-6. Figure 4-6 I/O Slot Numbering Removing I/O Cards You will need a T-15 Torx driver or ﬂathead screwdriver to remove the I/O slot bulkhead screws.
Page 84 Changing Your Workstation’s Hardware Conﬁguration I/O Cards 1. Power off the workstation, and unplug the workstation’s power cord from the electrical outlet. Note that when you press the workstation’s power switch, the workstation automatically performs a shutdown 2. Open the side panel of the workstation as explained in the section “Opening the Left Side Panel”...
Page 85: Installing I/O Cards
Figure 4-8 Removing the I/O Card I/O Card Bulkhead Screw I/O Card Bulkhead 5. Pull evenly on the outside edges of the I/O card to remove it. See Figure 4-8. Installing I/O Cards To install an I/O card into your workstation, follow these steps. NOTE The built-in V Use the secondary graphics slot (PCI slot 1) for the highest performance...
Page 86 Changing Your Workstation’s Hardware Conﬁguration I/O Cards appropriately positioned. See Figure 4-8. If the card is full length, the non-bulkhead end of the card should be placed in the I/O card guide. Press ﬁrmly and evenly on the I/O card until it is in the connector. Secure the I/O card to the bulkhead with the T-15 Torx screw.
Page 87: Fans
Fans The B2000 has three internal fans; processor turbo cooler fan, memory fan and the I/O fan. The power supply fan is integrated with the power supply circuitry and is not a stand alone component. Note the turbo cooler fan is mounted to the processor substrate and is not considered a user replaceable part.
Page 88: Removable Media Devices
Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices Removable Media Devices There are only two internal removable media devices allowed in a B2000 workstation: • CD drive • 3.5-inch ﬂoppy disk drive. The procedures provided in the subsequent sections explain how to install and remove removable media devices.
Page 89 2. Remove the CD drive bay’s rear cover by unscrewing the T-15 Torx/slotted screw as shown in Figure 4-10. Note that the CD drive’s rear cover is located on the rear of the removable media chassis inside the workstation. Push the cover handle away from the rear of the removable media chassis approximately one inch.
Page 90 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices Figure 4-12. Next remove the four CD drive blank ﬁller screws (T-15 Torx/slotted screws) as shown in Figure 4-12 and remove the blank ﬁller from the bracket. You are now ready to mount the CD drive into the CD drive bracket.
Page 91 5. Remove the CD drive from its shipping container and check to see that the jumper on the back of the CD drive is set to the C Select position. Using the four blank ﬁller screws (T-15 Torx/slotted screws) that were just removed, mount the disk drive to the bracket as shown in Figure 4-13.
Page 92 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 7. Plug the audio, ATAPI and power cables into their appropriate connectors. Note that the connectors are keyed for proper insertion. See Figure 4-14. To help with plugging in the audio connector, you can pull its cable through the back of the CD drive chassis to the front of the CD drive chassis and connect it.
Page 93 Figure 4-15 Tightening the Bracket Screws Bracket Screw Chapter 4 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices Bracket Screw (hidden)
Page 94 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 9. Make sure that the audio, ATAPI and power cables are positioned so that they come out of the bottom edge of the CD drive bay’s rear cover. This edge is rounded to prevent cutting of the cables. See Figure 4-16. Next, secure the CD drive bay’s rear cover using the T-15 Torx/slotted screw.
Page 95: Removing A Cd Drive
Removing a CD Drive This section explains how to remove a CD drive from your workstation. WARNING Turn the workstation off and unplug the power cord before removing the CD drive. CAUTION CD drives are susceptible to mechanical and electronic shock. When handling the drive, always wear the static-grounding wrist strap that came in the CD drive kit.
Page 96 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 2. Remove the CD drive bay’s rear cover by unscrewing the T-15 Torx/slotted screw as shown in Figure 4-17. Note that the CD drive bay’s rear cover is located on the back of the removable media chassis inside the workstation.
Page 97 3. Rotate the workstation around until you see the front of the unit as shown in Figure 4-18. Figure 4-18 Front of the Workstation with the Front Panel Removed workstation Power Switch Bracket Screw Chapter 4 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices Bracket Screw (hidden)
Page 98 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 4. Remove both CD drive bracket screws (T-15 Torx/slotted screws) and pull the CD drive out of the chassis assembly as shown in Figure 4-19. Next remove the four CD drive mounting screws (T-15 Torx/slotted screws) as shown in Figure 4-19 and remove the CD drive from the bracket.
Page 99 5. Insert the CD drive blank in the CD drive bracket and tighten the four CD drive mounting screws (T-15 Torx/slotted screws) using 6 inch-pounds of torque. This will secure the CD drive blank in place. Align the bracket runners and bracket guides and slide the CD drive blank and bracket into place.
Page 100 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 6. Tighten the two CD drive bracket screws as shown in Figure 4-21. These should be tightened using 6 inch-pounds of torque. Figure 4-21 Tightening the Bracket Screws Bracket Screw 7. Place the audio, ATAPI and power cables inside the CD drive bay, and position the cables so that they go under the bottom edge of the CD drive bay’s rear cover.
Page 101: Installing A Floppy Disk Drive
8. Replace the plastic CD drive blank in the workstation’s front panel. 9. Replace the left side panel and front panel of the workstation as explained in the sections “Closing the Left Side Panel” and “Closing the Front Panel” in this chapter. Installing a Floppy Disk Drive Install the ﬂoppy disk drive by following the procedure covered in this section.
Page 102 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 2. Remove the ﬂoppy disk drive bay’s rear cover by unscrewing the T-15 Torx screw as shown in Figure 4-23. Note that the ﬂoppy disk drive bay’s rear cover is located on the rear of the removable media chassis inside the workstation.
Page 103 3. Rotate the workstation around until you see the front of the workstation as shown in Figure 4-24. Figure 4-24 Front of Workstation with the Front Panel Removed Workstation Power Switch Chapter 4 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices CD Drive Blank Floppy Drive...
Page 104 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 4. Remove both ﬂoppy disk bracket screws (T-15 Torx/slotted screws) and pull the ﬂoppy disk bracket out of the chassis assembly as shown in Figure 4-25. Next remove the four ﬂoppy disk blank ﬁller screws (T-15 Torx/slotted screws) as shown in Figure 4-25 and remove the blank from the bracket.
Page 105 5. Remove the ﬂoppy disk drive from its shipping container. Using the four T-15 Torx/slotted blank ﬁller screws, mount the disk drive to the bracket as shown in Figure 4-26. To help you properly install the ﬂoppy disk drive, you need to use the ﬂoppy disk drive holes labeled “A”...
Page 106 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices chassis as shown in Figure 4-26. 7. Plug the ﬂoppy power cable into its connector. Next, plug the data cable into its connector. Note that the connectors are keyed for proper insertion. See Figure 4-27. NOTE The red striped side of the ﬂoppy data cable is positioned toward the power cable.
Page 107 Figure 4-28 Tightening the Bracket Screws Bracket Screw Chapter 4 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices Bracket Screw (hidden)
Page 108 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 9. Make sure that the ﬂoppy data and power cables are positioned so that they come out of the top edge of the ﬂoppy disk drive bay’s rear cover. This edge is rounded to prevent cutting of the cables. See Figure 4-29.
Page 109: Removing A Floppy Disk Drive
Removing a Floppy Disk Drive This section explains how to remove a ﬂoppy disk drive from your workstation. WARNING Turn the workstation off and unplug the power cord before removing the ﬂoppy disk drive. CAUTION Floppy disk drives are susceptible to mechanical and electronic shock. When handling the drive, always wear the static-grounding wrist strap that came in the ﬂoppy disk drive kit.
Page 110 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 2. Remove the ﬂoppy disk drive bay’s rear cover by unscrewing the T-15 Torx/slotted screw as shown in Figure 4-30. Note that the ﬂoppy disk drive bay’s rear cover is located on the rear of the removable media chassis inside the workstation.
Page 111 3. Rotate the workstation around until you can see the front of the workstation as shown in Figure 4-31. Figure 4-31 Front of Workstation with the Front Panel Removed Workstation Power Switch Floppy Disk Drive Bracket Screw Chapter 4 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices Bracket Screw...
Page 112 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 4. Remove both ﬂoppy disk bracket screws (T-15 Torx/slotted screws) and pull the ﬂoppy disk drive out of the chassis assembly as shown in Figure 4-32. Next remove the four ﬂoppy disk drive mounting screws (T-15 Torx/slotted screws) as shown in Figure 4-32 and remove the ﬂoppy disk drive from the bracket.
Page 113 5. Place the ﬂoppy disk blank in the ﬂoppy disk bracket and insert the four ﬂoppy disk mounting screws (T-15 Torx/slotted screws) into the bracket and tighten. See Figure 4-33. Figure 4-33 Installing the Floppy Disk Blank and Bracket Floppy Disk Mounting Screws (quantity 4)
Page 114 Changing Your Workstation’s Hardware Conﬁguration Removable Media Devices 7. Tighten the two ﬂoppy disk bracket screws as shown in Figure 4-34. Figure 4-34 Tightening the Bracket Screws Bracket Screw 8. Make sure that the ﬂoppy data and power cables are positioned so that they come out of the top edge of the rear ﬂoppy disk drive bay’s cover.
Page 115 Changing Your Workstation’s Hardware Conﬁguration panel. 10. Complete the removal of the ﬂoppy disk drive by replacing the front and side panels of the workstation as explained in the sections “Closing the Left Side Panel” and “Closing the Front Panel” in this chapter.
Page 116: Hard Disk Drives
Changing Your Workstation’s Hardware Conﬁguration Hard Disk Drives Hard Disk Drives This section describes how to install a hard disk drive in your workstation and how to remove it from your workstation. The ﬁrst section details how to install a hard disk drive. The second section details how to remove a hard disk drive.
Page 117: Installing A Hard Disk Drive
Installing a Hard Disk Drive This procedure explains how to install your hard disk drive in the slot that has been preassigned SCSI ID 5. On internal hard disk drives, the slot determines the addressing. There are no cables required when installing a hard disk drive.
Page 118 Changing Your Workstation’s Hardware Conﬁguration Hard Disk Drives Figure 4-36 The Hard Drive Slots Slots Power Supply 2. Loosen the captive T-15 Torx thumbscrew securing the disk drive tray to the system board. As you grasp the tray and slide to the front of the workstation, the tray will unseat from the chassis rail.
Page 119 Figure 4-37 Removing the Hard Disk Drive Bracket 3. Mount the hard disk drive on the hard drive bracket using the four T-15 Torx shoulder screws that are stored on the mounting bracket. See Figure 4-38 for location of the shoulder screws and Figure 4-39 for positioning the bracket to the hard disk drive.
Page 120 Changing Your Workstation’s Hardware Conﬁguration Hard Disk Drives Figure 4-38 T-15 Torx Shoulder Screws Figure 4-39 Positioning the Bracket to the Hard Disk Drive Chapter 4...
Page 121 4. Insert the T-15 Torx Hard Disk Mounting Screws through the rubber mounting grommets and into the screw holes located on the sides of the hard disk drive. See Figure 4-40. Figure 4-40 Inserting the Hard Disk Drive Hard Disk Drive Bracket Hard Disk Drive...
Page 122 Changing Your Workstation’s Hardware Conﬁguration Hard Disk Drives Figure 4-41 Positioning the Hard Disk Drive Assembly Chapter 4...
Page 123: Removing A Hard Disk Drive
Removing a Hard Disk Drive This procedure explains how to remove your hard disk drive. Note that there are no cables to disconnect when removing a hard disk drive. To remove a hard disk drive, your workstation must be turned off. NOTE If you are removing a hard disk drive that has a mounted ﬁle system on it, you will need to unmount it.
Page 124 Changing Your Workstation’s Hardware Conﬁguration Hard Disk Drives 2. Loosen the T-15 Torx thumbscrew securing the disk drive tray to the system board. As you grasp the bracket and slide to the front of the workstation, the bracket will unseat from the chassis rail. See Figure 4-43.
Page 125 3. Remove the four T-15 Torx shoulder screws from the hard disk drive and bracket. See Figure 4-44. You should be careful when removing the hard disk drive from its mounting bracket to avoid damaging it. Note that in order to remove the T-15 Torx screws from the sides of the hard disk drive you will have to have a T-15 Torx driver that is long enough to ﬁt through the access holes on the sides of the hard disk drive bracket.
Page 126 Changing Your Workstation’s Hardware Conﬁguration Hard Disk Drives 4. Replace the four mounting screws on the hard disk drive bracket to store them for future use. Slide the mounting bracket into its hard drive slot, and push ﬁrmly inward to secure the hard drive bracket to the system board connector.
Page 127: Conﬁguring A Hard Disk Drive As A File System
Changing Your Workstation’s Hardware Conﬁguration Conﬁguring a Hard Disk Drive as a File System This section describes how to add a hard disk drive to your workstation as a ﬁle system using SAM and how to remove the hard disk drive from your workstation.
Page 128 Changing Your Workstation’s Hardware Conﬁguration Hard Disk Drives 4. Double click on the Sam icon in the Application Manager -- System_Admin window. If you are root, the System Application Manager (SAM) will appear on your screen. 5. Double click on the Disks and File Systems icon. 6.
Page 129 Changing Your Workstation’s Hardware Conﬁguration 8. Enter the mount directory name (for example, /disk1) in the Mount Directory ﬁeld of the Add Disk without LVM window. 9. Click on the OK button in the Add Disk without LVM window. You will need to wait for a short time before the new ﬁle system is created and the hard disk drive is mounted.
Page 130 Changing Your Workstation’s Hardware Conﬁguration Hard Disk Drives 4. Double click on the Sam icon in the Application Manager -- System_Admin window. If you are root, the System Application Manager (SAM) will appear on your screen. 5. Double click on the Disks and File Systems icon. 6.
Page 131 Changing Your Workstation’s Hardware Conﬁguration 7. Click on Remove in the Actions menu. In the window that next appears, click on the Yes button. This will unmount the ﬁle system located on the hard disk drive you are removing from the workstation.
Page 132: Memory Cards
Changing Your Workstation’s Hardware Conﬁguration Memory Cards Memory Cards This section contains information regarding the installation and removal of memory (DIMM please take time to read the following list of considerations: • Use the procedure described in Chapter 5, “The Boot Console Interface,”...
Page 133 Figure 4-46 View of System Board DIMM Card NOTE Reference the B2000 system label for the correct memory loading sequence. Chapter 4 Changing Your Workstation’s Hardware Conﬁguration Power Supply Memory Cards DIMM Connector B2000 System Label...
Page 134 Changing Your Workstation’s Hardware Conﬁguration Memory Cards 2. Position the memory slots so they face you as shown in Figure 4-47. Note that Figure 4-47 also provides the loading sequence for the DIMM cards. This loading sequence must be maintained when you install the DIMM cards, but the size of the DIMM card put in each slot can vary.
Page 135 NOTE When installing memory, you need to orient the notches on the bottom edge of the DIMM card so that they are aligned with the keys on the DIMM connector. See Figure 4-49. The keyed DIMM connectors prevent you from installing the DIMM cards backwards. For referencing the DIMM loading sequence see the label on the chassis ﬂoor.
Page 136 Changing Your Workstation’s Hardware Conﬁguration Memory Cards 4. Press downward on the ejector tabs located on both sides of the DIMM connector. See Figure 4-49. This opens the connector for DIMM card insertion. Figure 4-49 Installing Memory Cards Step 1 Notches Step 2 Black...
Page 137 Changing Your Workstation’s Hardware Conﬁguration Memory Cards Once you have completed the steps listed above, your DIMM cards are properly loaded. Chapter 4...
Page 138: Removing Memory
Changing Your Workstation’s Hardware Conﬁguration Memory Cards Removing Memory Perform the following steps to remove memory (DIMM cards) from your workstation. WARNING Always unplug the workstation’s power cord from the electrical outlet or power source before opening the workstation. 1. Open the side panel of the workstation as explained in the section “Opening the Left Side Panel”...
Page 139 Changing Your Workstation’s Hardware Conﬁguration Memory Cards Figure 4-51 DIMM Slot Close-Up on System Board DIMM Connectors (4 slots) Chapter 4...
Page 140 Changing Your Workstation’s Hardware Conﬁguration Memory Cards 2. Press downward on the ejector tabs located on both sides of the DIMM connector. See Figure Figure 4-52. This raises the DIMM card for easy extraction. Figure 4-52 Removing Memory Cards Notches 3.
Page 141: Monitor Type
Changing Your Workstation’s Hardware Conﬁguration Monitor Type Your workstation ships from the factory preset to use a monitor with a speciﬁc resolution and frequency. If you replace your monitor with a different type, you must reconﬁgure your workstation to support it. There are three ways to conﬁgure your workstation to support a different monitor type.
Page 142: Setting The Monitor Type From The Boot Console Interface
163 in Chapter 5. Setting the Monitor Type Using SAM This method for setting the monitor type requires the use of the HP CDE interface. This means that you should have already set your monitor type using one of the methods deﬁned in a previous section, or you have an Instant Ignition workstation that boots up using the HP CDE interface.
Page 143 Changing Your Workstation’s Hardware Conﬁguration 4. Double click on the Sam icon in the Application Manager -- System_Admin window. If you are root, the System Application Manager (SAM) will appear on your screen. 5. Double click on the Display icon. 6.
Page 144 Changing Your Workstation’s Hardware Conﬁguration Monitor Type 8. Select the action Modify Monitor Type from the Action menu. You will see a window with a list of monitor type selections in it. Here is an example of a monitor type entry you may see: Entry Width 1280...
Page 145: Troubleshooting Monitor Problems
4. Power on the workstation. The workstation will now display the console to the terminal connected to Serial 1 port. Note that you can use a 9-pin to 9-pin serial cable (HP F1044-80002) to connect an HP OminiBook serial port to the workstation.
Page 146 Changing Your Workstation’s Hardware Conﬁguration Monitor Type Chapter 4...
Page 147: The Boot Console Interface
The Boot Console Interface This chapter describes the different features of the boot console interface and how to use them with your HP V B2000 workstation. ISUALIZE...
Page 148 The Boot Console Interface This chapter contains the following topics: • Accessing the Boot Console Interface • Boot Console Interface Features • Booting Your System • Searching for Bootable Media • Resetting Your System • Displaying and Setting Paths • Displaying and Setting the Monitor Type •...
Page 149: Accessing The Boot Console Interface
NOTE There is no need to login as root and execute the shutdown -q command to shut down the HP-UX operating system on your workstation before powering it off. When you turn off the power switch, your workstation automatically shuts down the operating system before terminating the power.
Page 150 The Boot Console Interface Accessing the Boot Console Interface If auto boot and auto search are both turned on, you will see the following message: Processor is booting from first available de- vice. To discontinue, press any key within 10 seconds.
Page 151: Boot Console Interface Features
The Boot Console Interface Boot Console Interface Features Boot Console Interface Features There are times when you want to interact directly with the hardware of your workstation before it boots the operating system. Your workstation provides a menu-driven boot console interface that allows you to perform special tasks, display information, and set certain system parameters, even if the operating system is unavailable.
Page 152 The Boot Console Interface Boot Console Interface Features ------ Main Menu -------------------------------------- Command ----------- BOot [PRI|ALT|<path>] PAth [PRI|ALT|CON|KEY|[<path>] Display or modify a path SEArch [DIsplay|IPL] [<path>] COnfiguration [<command>] INformation [<command>] SERvice [<command>] DIsplay HElp [<menu>|<commands>] RESET ----- Main Menu: Enter command > Description ----------- Boot from specified path...
Page 153 ------ Configuration Menu ----------------------------- Command ------- AUto [BOot|SEArch] [ON|OFF] BootID [<proc>] [<boot ID>] BootINfo BootTimer [0 - 200] CPUconfig [<proc>] [ON|OFF] DEfault FastBoot [ON|OFF] LanConfig MOnitor [LIST|<path> <type>] PAth [PRI|ALT|CON|KEY] [<path>] Display or modify a path SEArch [DIsplay|IPL] [<path>] SECure [ON|OFF] TIme [c:y:m:d:h:m:s] PreviousPower [ON|OFF] BOot [<menu>|<command>]...
Page 154 The Boot Console Interface Boot Console Interface Features ------ Information Menu ------------------------------- Command ------- BootINfo CAche ChipRevisions COprocessor FwrVersion LanAddress MEmory PRocessor SysConfig WArnings BOot [PRI|ALT|<path>] DIsplay HElp [<menu>|<command>] RESET MAin ------ Information Menu: Enter command > Description ----------- Display all system information Display boot-related information Display cache information Display revisions of VLSI and firmware...
Page 155 ------ Service Menu ----------------------------------- Command ------- ChassisCodes[<proc>|ON|OFF CLEARPIM EepromRead [<addr>] {<len>} MemRead <addr> [<len>] [<type>] PCIDelay [<value>] PDT [CLEAR] PIM [<proc> [HPMC|LPMC|TOC]] ScRoll [ON|OFF] BOot [PRI|ALT|<path>] DIsplay HElp [<menu>|<command>] RESET MAin ----- Service Menu: Enter command > Chapter 5 The Boot Console Interface Boot Console Interface Features Description -----------...
Page 156: Booting Your System
The Boot Console Interface Booting Your System Booting Your System You usually start your system by turning it on and waiting for HP-UX to boot automatically. However, you may not always want the usual boot sequence to occur. For example, you may want to start your system from an operating system that is stored on a device that is different from your usual boot device.
Page 157 ISL is the program that actually controls the loading of the operating system. By interacting with ISL, you can choose to load an alternate version of the HP-UX operating system. If you do not want to interact with ISL, you must enter no (N).
Page 158 The Boot Console Interface Booting Your System For example, if the usual kernel (/stand/vmunix) on your root disk (scsi.6.0) has become corrupted, and you wish to boot your system from the backup kernel (/stand/vmunix.prev), type the following at the ISL> prompt and press Enter: ISL>...
Page 159: Searching For Bootable Media
Searching for Bootable Media To list devices that contain bootable media, follow the directions in “Accessing the Boot Console Interface” earlier in this chapter, and then type the following at the prompt and press Main Menu: Enter command> search ipl The search command searches all buses.
Page 160: Resetting Your System
The Boot Console Interface Resetting Your System Resetting Your System To reset your system to its predeﬁned values, follow the directions in “Accessing the Boot Console Interface” earlier in this chapter, and then type the following at the prompt and press Main Menu: Enter command>...
Page 161: Displaying And Setting Paths
Displaying and Setting Paths A path is the hardware address of a device that is attached to the I/O system of your system. The path command sets the system paths shown in Table 5-1. The path command sets and displays the hardware address of a speciﬁed device attached to the I/O bus of your system.
Page 162 The Boot Console Interface Displaying and Setting Paths To display the current setting for a particular system path, follow the directions in “Accessing the Boot Console Interface” earlier in this chapter, and then type the following at the prompt and press Main Menu: Enter command>...
Page 163: Displaying And Setting The Monitor Type
Displaying and Setting the Monitor Type Your system ships from the factory preset to use a monitor with a speciﬁc resolution and frequency. If you replace your workstation’s monitor with a different type of monitor, you may have to reconﬁgure your system to support the new monitor.
Page 164 Graphics adapter installed in slot 4 graphics(4) and type is the numerical monitor type. See “Setting the Monitor Type” in a subsequent section for a list of types. For example, an HP V fxe graphics card (A4982A) installed in option slot 2 would be Note that graphics(2).
Page 165: Displaying The Current Monitor Conﬁguration
Displaying the Current Monitor Conﬁguration To display the current monitor conﬁguration for your system from the Conﬁguration Menu of the boot console interface, follow the directions in “Accessing the Boot Console Interface” earlier in this chapter. Once you are in the Boot Console Interface Main Menu, type the following command and press Enter Main Menu: Enter command>...
Page 166: Setting The Monitor Type
The Boot Console Interface Displaying and Setting the Monitor Type Setting the Monitor Type You can set the monitor type for a graphics adapter by typing the following at the prompt and pressing Enter: Configuration Menu: Enter command> monitor graphics( n ) tt where n is the number of the graphics adapter and tt is the monitor type.
Page 167: Setting The Monitor Type With Sam
Setting the Monitor Type with SAM The System Administration Manager (SAM) allows you to change the monitor type after the HP-UX 10.20 operating system with the 9912 Additional Core Enhancements (ACE) software bundle (December 1999) have been installed on your workstation. This section provides a brief explanation on how to set the monitor type using SAM.
Page 168 The Boot Console Interface Displaying and Setting the Monitor Type 2. Move the mouse pointer to the Application Manager control for tools and click the left mouse button. Alternatively you can execute sam at a terminal window command prompt and skip to step 5. 3.
Page 169 5. Double click on the Display icon. 6. Double click on the Monitor Conﬁguration icon in the Display window. The Monitor Conﬁguration window will have a monitor icon(s) in it that is/are associated with the graphics card(s) in your workstation’s I/O card slot(s).
Page 170: Setting The Monitor Type At Power On
The Boot Console Interface Displaying and Setting the Monitor Type Setting the Monitor Type at Power On If you replace your workstation’s monitor with a different monitor type, you need to let the workstation’s ﬁrmware know you made this change. To do this, reboot the system and use either the automatic monitor selection process or the boot console interface’s monitor command.
Page 171: Troubleshooting Monitor Problems
4. Power on the system. The system will now display the console to the terminal connected to Serial 1 port. Note that you can use a 9-pin to 9-pin serial cable (HP F1044-80002) to connect an HP OmniBook serial port to the workstation.
Page 172: Changing The Console To An External Terminal
The Boot Console Interface Changing the Console to an External Terminal Changing the Console to an External Terminal In the event that your console stops displaying to your graphics device, use the following procedure to display the console to an external serial terminal so that you can conﬁgure the graphics console: 1.
Page 173: Displaying The Current Memory Conﬁguration
Displaying the Current Memory Conﬁguration Displaying the Current Memory Conﬁguration The following sample screen output uses the memory command to show a memory conﬁguration table with properly-installed and conﬁgured memory. To display the current memory conﬁguration for your system, from the Information Menu of the boot console interface, follow the directions in “Accessing the Boot Console Interface”...
Page 174: Memory Information Sample
The Boot Console Interface Displaying the Current Memory Conﬁguration Memory Information Sample The following example shows the memory information when memory modules are properly installed and conﬁgured: MEMORY INFORMATION MEMORY STATUS TABLE Slot Size Status ---- ------ ------------- 256MB Active 256MB Active 128MB...
Page 175: Displaying The Status Of The System I/O
The Boot Console Interface Displaying the Status of the System I/O Displaying the Status of the System I/O The io command lets you identify all built-in I/O devices and optional I/O devices installed in the option slots. It is available in the Information Menu.
Page 176: Setting The Auto Boot And Auto Search Flags
The Boot Console Interface Setting the Auto Boot and Auto Search Flags Setting the Auto Boot and Auto Search Flags The auto boot and auto search ﬂags are variables stored in your system’s nonvolatile memory. (Nonvolatile memory retains its contents even after power is turned off.) If you reset these ﬂags to new values, the change takes effect the next time you reboot the workstation.
Page 177 Setting the Auto Boot and Auto Search Flags The auto search command searches for devices in the following order: Primary boot path (can be set by the user) Alternate boot path (can be set by the user) PCI 1 through PCI 4 (plug-in interface cards) Low-voltage differential SCSI (built-in) LAN (built-in) IDE (built-in)
Page 178: Displaying And Setting The Security Mode
The Boot Console Interface Displaying and Setting the Security Mode Displaying and Setting the Security Mode The secure ﬂag is a variable stored in non-volatile memory. (Non-volatile memory retains its contents even after power is turned off.) If you reset this ﬂag to a new value, the change takes effect the next time you reboot the workstation.
Page 179: Displaying And Setting The Fastboot Mode
Displaying and Setting the Fastboot Mode When fastboot is enabled (set to on), your system does a quick check of the memory and skips I/O interface testing during its power-on self tests. This enables your system to complete its boot process quicker. The default factory setting is for fastboot to be enabled (set to on).
Page 180: Displaying The Lan Station Address
The Boot Console Interface Displaying the LAN Station Address Displaying the LAN Station Address It is sometimes necessary to supply the LAN station address of your workstation to other users. For example, if your workstation is to become a member of a cluster, the cluster administrator needs to know your LAN station address in order to add your workstation to the cluster.
Page 181: Displaying System Information
The Boot Console Interface Displaying System Information Displaying System Information The all command allows you to display the system’s processor revision and speed, cache size, memory size, ﬂag settings, and the boot and console paths. To display system information for the Information Menu, type the following at the prompt and press Enter Information Menu: Enter command>...
Page 182 The Boot Console Interface Displaying System Information Chapter 5...
Page 183: Solving Problems
Solving Problems This chapter contains information to help you determine what is wrong with your system when you have problems. If you have a problem that is not listed in this chapter, or if your problem persists, contact your designated service representative.
Page 184 Workstation Additional Core Enhancements for HP-UX 10.20 (December 1999) with the HP CDE graphical interface. When using HP CDE, you will have to use command line options in a terminal window to perform tests. Here are the topics covered in this chapter: •...
Page 185: Common Problems And Solutions
Common Problems and Solutions The tables in this section lists common problems you may encounter with your computer. The tables also tell you what to do to help solve the problems. Table 6-1 Problems Powering Up the System The LCD screen does not light up.
Page 186 Solving Problems Common Problems and Solutions Table 6-2 Problems Loading and Booting the Operating System The LCD screen is lit, and text appears on the screen, but more than two minutes have passed with no sign of system activity. The system stops or hangs while booting.
Page 187 Table 6-4 Problems Using a Hard Disk Drive The disk drive is not accessible or does not respond. If problems persist, contact your system administrator or call your designated service representative. Table 6-5 Problems Using the CD Drive The CD drive does not respond to commands (for example, mount or swinstall).
Page 188 Make sure cables (power, data, etc.) are connected. A patch is available from HP that adds the proper IDE choices to the SAM screen. You may load this patch from the HP Electronic Support Center. Reference the following URL: http://us-support.external.hp.com/...
Page 189: Dealing With A Boot Failure
Dealing with a Boot Failure If your usual boot device (typically a disk) is not responding as it should, you must try to boot from the disk (or another boot device) by selecting it manually. Note that you must be superuser (root) to perform the steps in this section.
Page 190 5. If your computer still fails to boot, there is either something wrong with the ﬁle system or with the hardware. If you suspect a ﬁle system failure, see the manual Using HP-UX for help on dealing with ﬁle system failures. If you think that something is wrong with the hardware, continue reading this chapter for more troubleshooting information.
Page 191: Memory Failures
Solving Problems Memory Failures Memory Failures A memory failure will show up in the LCD on your system unit’s front panel as a DIMM error. Your system’s Boot Console Interface will never appear. A possible solution to the memory failure problem is to perform the procedure in the section “Installing Additional Memory”...
Page 192: Lcd Information
Solving Problems LCD Information LCD Information Your computer uses an LCD panel to display ﬁrmware/OS progress codes. The codes, referred to as chassis codes, consist of one of the mnemonics listed below, followed by a 4-digit hexadecimal number identifying the code module being executed. The mnemonics and their meanings are: A hardware error has been detected Hardware being tested...
Page 193: Lcd Fan Failures And Warnings
If the system encounters a FLT code while the system is booting, the FLT code is interpreted and a message is displayed. For example, you may have information similar to the following in the LCD: 30FC SYS BD bad sys bd id LCD Fan Failures and Warnings This section provides the failure and warning messages you will see in your computer’s LCD if there is a problem with a fan in your system unit.
Page 194 If you should receive a failure or warning in you LCD, you should record the information on a piece of paper and call in the problem to your local HP Support Representative. The representative will want the LCD failure or warning message you record for determining the course of action to take regarding possible repairs.
Page 195: Troubleshooting Monitor Problems
4. Power on the system. The system will now display the console to the terminal connected to Serial 1 port. Note that you can use a 9-pin to 9-pin serial cable (HP F1044-80002) to connect an HP OminiBook serial port to the workstation.
Page 196: Running System Veriﬁcation Tests
HP-UX uses a diagnostics product called Support Tools Manager (STM), which allows system operation veriﬁcation. To use STM, you need to be on an HP-UX 10.20 operating system and to load the Workstation Additional Core Enhancements for HP-UX 10.20 (December 1999) HP-UX Support Plus Media on your computer.
Page 197: Safety And Regulatory Statements
Safety and Regulatory Statements This appendix contains safety and regulatory statements pertaining to your HP V B2000 workstation. ISUALIZE...
Page 198 Safety and Regulatory Statements Here are the topics covered in this appendix: • Declaration of Conformity • Emissions Regulations • Third Party Emissions Regulations Compliance • Special Regulatory and Safety Information • Warnings and Cautions Appendix A...
Page 199: Declaration Of Conformity
UL Listed to UL1950, 2nd edition, File E146385 cUL Listed to CSA 22.2 No.950-M93 TUV Certiﬁed to EN60950 2nd edition with A1+A2+A3+A4+A11 HP Fort Collins CCQD HQE supplementary information: The product herewith complies with the requirements of the following Directives and carries the CE...
Page 200: Emissions Regulations
• Ask the dealer or an experienced radio/television technician for help. Hewlett-Packard's system certiﬁcation tests were conducted with HP- supported peripheral devices and HP-shielded cables, such as those you receive with your workstation. Changes or modiﬁcations not expressly approved by Hewlett-Packard could void the user's authority to operate the equipment.
Page 201: Emi Class A Rrl (Korea)
Operation of this device is subject to the following conditions: • This device may not cause harmful interference. • This device must accept interference received, including interference that may cause undesired operation. • Cables used with this device must be properly shielded to comply with the requirements of the FCC.
Page 202: Emi Class A (Taiwan)
EMI Class A (Taiwan) Special Video Conﬁguration Statement When a Video Out card has a cable connected to its video out connector, the HP V B2000 workstation no longer meets FCC Class B ISUALIZE regulations. The workstation now becomes FCC Class A compliant. This statement applies only to those applications which include a cable connected to the video out connector on a Video Out card.
Page 203: Third Party Emissions Regulations Compliance
Third Party Emissions Regulations Compliance Third Party Emissions Regulations Compliance Any third-party I/O device installed in HP system(s) must be in accordance with the requirements set forth in the preceding Emissions Regulations statements. In the event that a third-party noncompliant I/O device is installed, the customer assumes all responsibility and liability arising therefrom.
Page 204: Special Regulatory And Safety Information
Safety and Regulatory Statements Special Regulatory and Safety Information Special Regulatory and Safety Information This section covers regulatory and safety information for acoustics, lasers, and LEDs. Acoustics Table A-1 Regulation On Noise Declaration For Machines -3. GSGV Lpa <70dB operator position normal operation per ISO 7779 Laser Safety Statement (U.S.A.
Page 205: Warnings And Cautions
Safety and Regulatory Statements Warnings and Cautions Warnings and Cautions WARNING: Removing device cover may expose sharp edges in equipment chassis. To avoid injury, use care when installing customer add-on devices. WARNUNG: Das Entfernen der Geräteabdeckung legt die scharfen Kanten im Inneren des Gerätes frei.
Page 206 Safety and Regulatory Statements Warnings and Cautions Appendix A...
Page 207 Glossary Absolute pathname The full pathname of a ﬁle, including all the directories leading to it, starting with the root directory (“/”) and ending with the ﬁlename itself. See also ﬁle, ﬁlename, pathname. Access permissions Settings that allow or prevent a user or group of users to read, write, or execute ﬁles.
Page 208 Glossary diskless workstations. See also boot ROM. Boot console interface The interactive ﬁrmware that enables you to interact with the hardware of your workstation before the workstation boots the operating system. The boot console interface allows you to perform special tasks, display information, and set certain system parameters.
Page 209 ﬁle-system server for the cluster clients. See also cluster client, cluster node, cluster server. Cluster client. A cluster node that does not have a local HP-UX ﬁle system. Its ﬁle system resides on the cluster server. See also cluster, cluster node, cluster server.
Page 210 (typed at the keyboard or read from a ﬁle) and interprets them as requests to execute commands or programs. An HP-UX command interpreter is called a shell. See also shell. Command option Information you provide on a command line to...
Page 211 This automatic option is called the “default.” See also command option. Dialog box A special type of HP CDE screen that contains controls and settings, and with which the user can carry on an interactive “dialog” in the process of setting whatever parameters the dialog box requests.
Page 212 Glossary Drag To move the mouse (and hence the pointer on the screen) while holding down one or more of its buttons. This process speciﬁes two separate locations on the screen for those operations that require two: the location when the mouse button is pressed, and the location when it is released.
Page 213 ﬁle (such as opening the ﬁle or writing to it) See also access permissions. File manager The HP CDE application that allows you to manage your ﬁles and directories, and to set viewing preferences.
Page 214 Glossary is opened by the drive when access is needed. Help manager The HP CDE application that provides online help. $HOME The environment variable that contains the name of a user’s home directory. This is the directory in which you are placed upon logging in.
Page 215 Glossary Input device Any of several pieces of hardware equipment used to give information to a system. Examples include the keyboard and the mouse. See also output device. Input window The window that displays a program’s prompt and any commands typed but not yet executed.
Page 216 (LAN) connection for your workstation at the hardware level. This 48-bit number is preassigned by HP on their computers and it must never be changed. Log in v. To initially sign on to the system so that you may begin to use it.
Page 217 Operating system The program that supervises the execution of other programs on your workstation. For example, the entire HP-UX system, including the kernel and all HP-UX commands. See also kernel. Option See command option. Output device Any of several pieces of hardware used for...
Page 218 (this is used as a visual feedback mechanism from a program to the user). In the HP CDE Workspace, the default pointer is an X; on a window frame, it is either a simple arrow, or an arrow with one or...
Page 219 Program. A unit of executable code, in source-code or binary form. Most HP-UX commands and routines consist of programs. Prompt A message or symbol displayed by the system to let you know that it is ready for your input.
Page 220 Glossary Shell A command-line interpreter program used to invoke programs. Some examples of HP-UX shells are the Bourne, Korn, Key, and C shells. Sometimes referred to as a “command interpreter.” See also command interpreter. Shell command An instruction you give the system to execute a utility program or shell script.
Page 221 System name See internet protocol address. Terminal window A terminal window is a type of HP CDE window that emulates a complete display terminal. Terminal windows are typically used to fool window-dumb programs into believing they are running in their favorite terminal.
Page 222 ﬁle or displaying the contents of a directory. See also command, shell command. Window A rectangular area of the screen for viewing information. HP CDE allows you to create several types of windows on the screen. Each window is a separate...
Page 223 Glossary Workspace What the screen becomes when you start HP CDE. Although you can hide the workspace under terminal windows or other graphic objects, you can never position anything behind the workspace. All windows and graphic objects appear stacked “on top of ” the workspace. See also HP Common Desktop Environment, terminal window.
Page 225 Index Numerics 802.3 network Problem Solution 802.3 twisted pair LAN connector Applications, FCC B Audio connectors Audio electrical speciﬁcations auto boot Auto boot, setting auto search Auto search, setting B2000 key features Bezel latch button Bezel lock boot Boot console interface features Boot console interface menu Conﬁguration Information...
Page 226 Hardware address Hardware conﬁguration Left side panel of the system unit System unit front panel Headphones jack Host name HP Year 2000 Warranty I/O card Installing Removing Slot number and capabilities I/O card slots, rear panel I/O, displaying the status of the system...
Page 227 Index Instant Ignition Instant ignition Instant Information Interface, user Internal storage devices Internet protocol (IP) address Internet protocol address ioscan IP address ipl device type disk pcin scsi Japan, VCCI Class B ITE Keyboard, USB Korea RRL LAN station address, displaying LAN station ID lan, ipl device type lanaddress...
Page 228 Index Network, standard Operating system Operating system overview Parallel connector Parallel connector, IEEE 1284 Parallel I/O connector Parallel port (IEEE 1284) path Path type alternate or alt console or con keyboard or key primary or pri Paths, displaying and setting PCI slots pcin, ipl device type Peripheral component interconnect (PCI)
Page 229 Unloading, CD-ROM Unmounting, CD-ROM Keyboard USB connectors Index USB ports User interface VCCI Class B ITE (Japan) Verifying, CD drive Video conﬁguration statement, special Warnings and cautions Warranty Workstation ACE for HP-UX 10.20 (December 1999) Write-protect tab, ﬂoppy diskette xstm...

This manual is also suitable for:

Vizualize,visualize b2000 Visualize b2000 - workstation Visualize b2000

HP Visualize c3700 Owner's Manual

1 Overview

2 Using Your CD Drive

3 Using Your 3.5-Inch Floppy Disk Drive

4 Changing Your Workstation's Hardware Conﬁguration

5 The Boot Console Interface

6 Solving Problems

Safety and Regulatory Statements

Quick Links

Troubleshooting

Related Manuals for HP Visualize c3700

Summary of Contents for HP Visualize c3700

This manual is also suitable for:

Table of Contents
