HP Visualize c3700 Owner's Manual page 135

NOTE
Figure 4-48
When installing memory, you need to orient the notches on the bottom
edge of the DIMM card so that they are aligned with the keys on the
DIMM connector. See Figure 4-49. The keyed DIMM connectors prevent
you from installing the DIMM cards backwards.
For referencing the DIMM loading sequence see the label on the
chassis floor. See Figure 4-48.
B2000 System Label
Chapter 4
Changing Your Workstation's Hardware Configuration
Memory Loading Sequence on
B2000 System Label
Memory Cards
Front of the
B2000
workstation
135
