6.12 Dog Sports, Program 14

There are different competitions for dog sport agility. The standad program "challenge" is available in
TdC 8001.
6.12.1

Challenge, Program 141

The programs for agility are not described in this manual. The program is almost identical with the pro-
gram show jumping. We recommend to use the separate manual for show jumping to work with this
program.

6.13 TdC Test, Program 15

With this program device testing as well as check of display and keypad can be carried out. The test
program is used for tests after production. The TdC test is a manufacturer test and has no significance
for the normal operation.
Activation procedure:
− turn on TdC 8001 (switch g)
− select program TdC TEST (prog. no. 9) with cursor keys, <ENTER>
info display (7) shows
−
Menu 48: GENERAL MESUREMENTS
Select: YES/NO or menu number: 48
select desired program with cursor keys:
−
general measurements
−
− display test
keypad test
−
− confirm with <ENTER>
General measurements, menu 48
When selecting general measurements, the info display shows as follows:
Menu 48: GENERAL MEASUREMENTS
UB= 8.5V IB=+0.00A TB=+23.9° CLOCK
UE= 5.0V IE=+0.00A TL=-69.5° PRINTER
Continue: ENTER
Info display (7) shows in second line the battery voltage (UB), the battery energy (IB) and battery tem-
perature (TB). In third line the stabilized external voltage (UE) is indicated. It should be about 5 V. Further
the charging rate of extender devices (IE) is shown. Extender devices are connected to RS485 interface.
The current must remain below 1A. In addition a measurement with TL is shown. This measurement has
not yet been activated and can indicate any value.
Check battery with <F1>:
− Press <F1> until info display (7) shows BATT L<. This means that the battery is charged when
the charging device is connected. (IB) must show positive value (about +2 A)
− Press <F1> until info display (7) shows BATT E<. This means that the battery is discharged.
The energy (IB) must show negative value (about – 1.6 A).
With <F2> the CLOCK impulse of the RS485 interface is checked with oscilloscope
With <F3> the character set of the printer is issued
With <F4> the external speaker is operated
Manual
TdC 8001
menu 48
menu 49
menu 50
BATT
SPEAKER
-97-
F1 battery test
F2 clock of RS485
F3 printer test
F4 speaker test
