Modify times:
In Dual Timer the times can be copied from one start number to another, invalid times can be made valid
or times can be entered manually. Use <INPUT> of keypad (12) to change times of the blue course, the
one of keypad (8) for changing times of the red course.
−
Change finish time of corresponding course with <INPUT>
Change start time of corresponding course with <ALT> and <INPUT>
−
−
Change run and intermediate times of corresponding course with <MENU> and <INPUT>
Ranking:
A ranking can be issued for both or for each individual course.
Rank calculation:
The rank calculation can be carried out for both courses or for each of them separately. Settings for rank
calculation in main menu (menu 30: rank calculation).
Start channel:
The start can take place for both courses at the same time or for each one of them separately. Settings
for start procedure in main menu (menu 29: start channel). If the joint start channel is used, the time for
both courses is started no matter if channel c0 or channel c3 was triggered.
Course identification:
The courses can be marked with r (red) and b (blue) or r (right) and l (left). Selection for marking in main
menu (menu 27: channel ID 4).
Channel assignment
c0
= start channel red (right)
c1
= finish channel blue (left)
c2
= intermediate time 1 red (right)
c3
= start channel blue (left)
c4
= finish channel blue (left)
Default main menu:
Menu 1
delay time start
Menu 2
delay time finish
Menu 3:
seconds mode
Menu 4:
display time 1
Menu 5:
display time 2
Menu 8:
running time
Menu 9:
running tenth
Menu 10:
intermediate time rank
Menu 11:
run time rank
Menu 14:
print start time
Menu 16:
paperfeed
Menu 17:
RS232 baud rate
Menu 18:
RS232 run time
Menu 19:
d-board baud rate
Menu 20:
d-board channel 2
Menu 21:
beep
Menu 23:
groups
Menu 24:
change heat
Menu 25:
change race
Menu 26:
d-board test
Menu 27:
ID channel 4
Menu 29:
start channel
Menu 30:
rank calculation
Menu 55:
LED-brightness
Menu 59:
pulse from radio
Menu 62:
extern beep
Manual
TdC 8001
c5
= intermediate time 1 blue (left)
c6
= intermediate time 2 red (right)
c7
= intermediate time 2 blue (left)
c8
= intermediate time 3 red (right)
c9
= intermediate time 3 blue (left)
=
1.0 sec.
=
0.3 sec.
=
off
=
3 sec.
=
3 sec.
=
heat
=
off
=
on
=
on
=
off
=
0
=
9600 baud
=
off
=
2400 baud
=
running
=
on
=
off
=
b (blue)
=
separate
=
separate
=
9
=
all channels off
=
all channels off
-72-
