ALGE-Timing TDC8001 Manual page 47

Print Time Speed Measurement, Menu 31
In program 7 speed measurement you can set if the time of days and net time of the speed measurement
should also be printed.
Menu 31: PRINT TIMES
Save with: ENTER
Print times = off:
0001 km/h
0002 km/h
Print times = on
0001 C0 13:49:41.8501
0001 C1 13:49:42.1001
RT 0:00.2490
km/h
0002 C0 13:59:45.2413
0002 C1 13:59:45.5413
RT 0:00.2990
km/h
Measuring Distance Speed Measurement, Menu 32
The measuring distance between both photocells can be set between 1 and 9999 m. It is always entered
in meter independent from the unit.
Menu 32: DISTANCE = 0100 m
Save with: ENTER
Unit Speed Measurement
Input the unit for speed measurement. Select from km/h, m/s and mph.
Menu 33: UNIT
Save with: ENTER
Minimum Speed
Input the minimum speed that should be measured. Every speed below this value is not valid. Input of
1 to 9999 is possible.
The unit of menu 33 also applies for this menu. The entered minimum speed is automatically converted
into the new unit.
Menu 34: MIN.SPEED = 0010 kmh
Save with: ENTER
Maximum Speed
Input the maximum speed that should be measured. Every speed exceeding the entered value is invalid.
Input of 1 to 9999 is possible.
The unit of menu 33 also applies for this menu. The entered maximum speed is automatically converted
into the new unit.
Menu 35: MAX.SPEED = 0200 kmh
Save with: ENTER
Manual
TdC 8001
144.23
120.08
144.23
120.08
Menu 33
Menu 34
Menu 35
Default = OFF
ON F1 times and speed
OFF < F2 only speed
exit with <ENTER>
Default = 0100 m
input measuring distance
exit with <ENTER>
Default = km/h
kmh < F1 kilometres per hour
mps F2 meter per seconds
mph F3 miles per hour
exit with <ENTER>
Default = 0010 km/h
enter minimum speed
exit with <ENTER>
Default = 0200 km/h
enter maximum speed
exit with <ENTER>
-47-
