ALGE-Timing TDC8001 Manual page 55

Printer: example for a printout
1 heat:
st
0001 ST 10:05:58.9903
0001 FT 10:07:20.2343
RT 1:21.24
2 heat:
nd
0001 ST 10:07:01.4858
0001 FT 10:08:22.3854
RT 1:20.90
MT 1:21.24
TT 2:42.14
Display Board GAZ5:
The net time and start number/rank can be displayed on every ALGE display board. Always the current
number shown in display (6) is shown (on the display board the number is three-digit, the rank two-digit).
channel 2 can be activated in the main menu (see menu 20). When working with channel 2, only the
stopped time is shown on the display board (no running time).
Start number/
Rank
Run time and
Running time
RS232 interface: see chapter 8.2
Manual
TdC 8001
start time
finish time
run time
start time
finish time
run time
memory time e.g. 1 heat
st
total time
thumbwheel switch
-55-
toggle switch
on 0
thumbwheel toggle switch
auf 0
up
middle
