Plug assignment: see chapter 8.1.5
cable from TdC 8001 to PC (9-pin)
cable from TdC 8001 to PC (25-pin)
In the mainmenu the following can be set:
RS232 Baud rate:
Set baud rate for RS232 interface (d) on 2400, 4800, 9600 or 19200 baud.
Menu 17: RS232 BAUD RATE
RS232 Run time
In difference time mode the stopped times of day are always output via the RS232 interface (d). In
addition the run times can be sent.
Menu 18: RS232 RUN TIME
Save with: ENTER
8.2.1

Inquiry of Device Settings via RS232 Interface

Precision
RS232 inquiry
TdC 8001 response
Timing mode
RS232 inquiry
TdC 8001 response
Laps at split sequential
RS232 inquiry
TdC 8001 response
8.2.2

Settings of Main Menu via RS232 Interface

Delay time start ..................... menu 1
RS232 inquiry ......................... DTS?
RS232 command .................... DTS=0.30
adjustable ............................... 0.00 – 9.99 sec
Delay time finish ................... menu 2
RS232 inquiry ......................... DTF?
RS232 command .................... DTF=0.30
adjustable ............................... 0.00 – 9.99 sec
Seconds mode ...................... menu 3
RS232 inquiry ......................... SM?
RS232 command .................... SM=ON
adjustable ............................... ON or OFF
Display time 1 ....................... menu 4
RS232 inquiry ......................... DIT1?
RS232 command .................... DIT1=03
adjustable ............................... 0 – 99 seconds
Display time 2 ....................... menu 5
RS232 inquiry ......................... DIT2?
RS232 command .................... DIT2=03
adjustable ............................... 0 – 99 seconds
Display thousandth .............. menu 6
RS232 inquiry ......................... DI1/1000?
RS232 command .................... DI1/1000=ON
adjustable ............................... ON or OFF
Manual
TdC 8001
067-02
066-03
menu 17
2400 Bd
4800 Bd
9600 Bd<
19200 Bd
menu 18
EIN
AUS <
PRE?
PRE = 1 s
PRE = 1/10 s
PRE = 1/100 s
PRE = 1/1000 s
TI=?
TI = DIFFERENC
TI = ABSOLUT
LAPS =?
LAPS = 4
Info Display ........................... menu 7
RS232 inquiry ......................... IDIS?
RS232 command .................... IDIS=START
adjustable ............................... START, FINISH, OFF
Running time ........................ menu 8
RS232 inquiry ......................... RT?
RS232 command .................... RT=RUN
adjustable ............................... RUN or TOTAL
Running tenth ....................... menu 9
RS232 inquiry ......................... R1/10?
RS232 command .................... R1/10=OFF
adjustable ............................... ON or OFF
Intermediate time rank ......... menu 10
RS232 inquiry ......................... RNKIT?
RS232 command .................... RNKIT=ON
adjustable ...............................
Run time rank ....................... menu 11
RS232 inquiry ......................... RNKFT?
RS232 command .................... RNKFT=ON
adjustable ............................... ON or OFF
Start number automatic ....... menu 12
RS232 inquiry ......................... STNOA?
RS232 command .................... STNOA=OFF
adjustable ............................... ON or OFF
-104-
Default = 9600 Bd
F1
F2
F3
F4
Default = OFF
F1 run time and time of day output
F2 only time of day output
confirm with <ENTER>
precision seconds
precision tenth of a second
precision hundredth of a second
precision thousandth of a second
difference timing
absolute timing
set number of laps (1-99)
