ALGE-Timing TDC8001 Manual page 44

Printer Linefeed
The printer can make blank lines after a printed paragraph (e. g. two blank lines so that the printout
moves across the tear-off edge). 1 to 9 blank lines can be set; if set to 0, in every line is printed.
Menu 16: PRINTER LINEFEED = 0
Save with: ENTER
RS232 Baudrate
The baud rate for RS232 interface (d) can be set to 2400, 4800, 9600, 19200 Baud.
Menu 17: RS-232 BAUDRATE
Save with: ENTER
RS232 Run Time
In difference time mode the stopped time of days is always output via RS232 interface (d). Additionally,
the run time can be output.
Menu 18: RS-232 RUN TIME
Save with: ENTER
Display Board Baudrate
The display board interface can be set to 2400, 4800, 9600 or 19200. For ALGE displays use 2400 Bd.
Starting with version V13.31 it is possible to turn the interface off (disable). To disable press the <arrow
key up> and then <F1>. With this version it sends the display board data also through RS485.
Starting with version V14.91 is the baud rate not automatically on 2400. The last used baud rate will
remain.
Menu 19: D-BOARD BAUDRATE
Save with: ENTER
Display Board channel 2
The output can be set at channel 2 of the interface display board (e). Running time, standing times, or
best times can be output. The best time is always from the group if groups are used. For displaying the
best time the code switch of the display has to be set to position 2. A ranking is always output via the
display board interface (e) at channel 2. Switch between channel 1 and 2 by turning the plug by 180°.
Menu 20: D-BOARD CHANNEL 2
Save with: ENTER
Beep
The beep sounds at every timing impulse. The length of the beep depends on the length of the delay
time. If the beep disturbs, it can be turned off. The beep is always activated after turning the device on.
Menu 21: BEEP
Save with: ENTER
Manual
TdC 8001
Menu 16
Menu 17
2400 Bd
4800 Bd
9600 Bd <
19200 Bd
Menu 18
ON
OFF<
Menu 19
2400 Bd
4800 Bd
9600 Bd <
19200 Bd
Menu 20
RUNNING <
STANDING
BEST TIME
Menu 21
ON
OFF <
WITH VALUED TIME
-44-
Default = 0
enter number of blank lines
confirm selection with <ENTER>
Default = 9600 BD
F1
F2
F3
F4
Default = OFF
F1 output of run time
F2 no output of run time
confirm selection with <ENTER>
Default = 2400 Bd
F1
F2
F3
F4
Default = RUNNING
F1 output of running time
F2 output of standing time
F3 output of best time
Default = ON
F1 beep activated
F2 beep deactivated
