ALGE-Timing TDC8001 Manual page 49

Count Down Time 1
Countdown time for carving and show jumping can be entered (carving: 0 to 23:59:59.99, show jumping:
0 to 6399.99 seconds). This time applies to all participants (main course at show jumping).
Menu 43: COUNT DOWN TIME 1 = 00:01:00.00
Save with: ENTER
Count Down Time 2
Countdown time for 2
nd
This countdown time applies to all participants.
Menu 44: COUNT DOWN TIME 2 = 0030.00
Save with: ENTER
Count Down for GAZ
Countdown for show jumping can be deactivated for display boards. If it is deactivated for the display
board, all other countdown functions stay activated.
Menu 45: D-BOARD COUNT DOWN
Save with: ENTER
Time Out Signal
The tone signal output for the timeout you can switch on or off.
Add PTM immediately
This menu is only for show jumping. PTM are penalty points caused through time violence. This menu
has only influence for the data output for display boards. Setting the menu on ON it shows the penalty
points when the time is running immediately. When OFF is activated it shows the PTM only after you
add the result by pressing the key F3.
Teams
This point is only for team show jumping events. If you select ON you can input the bibs of each team.
Distance
To input the race distance for the program Cycling. The distance is needed to calculate the average
speed. You can input the distance between 0 and 999999 Meter.
Speed Skating Track
For speed skating you have to select the track length to calculate the amount of laps. You can select
between 333, 400 and 500 m. Further you can input yourself the track length in meter.
Precision
This menu is not active any more. You must input the timing precision after you selected the program.
BIB Counting
You can select if the bib changes after a start. When selecting <MANUAL> you have to key in the next
bib. When selecting <UP> after the start the bib changes to the next higher free bib (in the second run
when using the BIBO it will change the bib to the next bib by bibo-rule). When selecting <DOWN> after
the start the bib changes to the next lower free bib.
Menu 53: BIB COUNTING
Save with: ENTER
Attention: Enter start number 0 with start keypad for fast deactivation of automatic counting; automatic
counting is blocked.
Time Out
Used for show jumping and agility. When you input a time limit it disqualifies the competitor when this
time is reached. The time is adjustable between 0 and 999 seconds. When using 0 there is no time limit.
Manual
TdC 8001
Menu 43
Menu 44
phase at show jumping can be entered. A time from 0 to 6399.99 is adjustable.
Menu 45
Menu 46
Menu 47
Menu 48
Menu 49
Menu 51
Menu 52
Menu 53
Menu 54
Default = 00:01:00.00
enter countdown time
exit with <ENTER>
Default = 00:01:00.00
enter countdown time
exit with <ENTER>
Default = ON
ON < output to display board
OFF no output on GAZ
exit with <ENTER>
Default = ON
Default = OFF
Default = OFF
Default = 0
Default = 400 m
Default = UP
UP < counting up
MANUAL manual input
counting down
DOWN
exit with <ENTER>
Default = 0 seconds
-49-
