- Page 1 Version: V140116 Manual Jumping...
- Page 2 Important Information General Before using your ALGE-TIMING device read the complete manual carefully. It is part of the device and contains important information about installation, safety and its intended use. This manual cannot cover all conceivable applications. For further information or in case of problems that are mentioned not at all or not sufficiently detailed, please contact your ALGE-TIMING representative.
- Page 3 Manual TIMY2 – Jumping Table of Contents Control Elementes ....................... 4 Gerneral ........................4 Select Program Jumping .................... 5 Jumping Modes ......................5 Squat Jump ......................5 Counter Movement Jump ..................6 Drop Jump ......................6 Power Test 15s, 30s and 60s ................6 Interface for display board ..................
- Page 4 Manual TIMY2 – Jumping Control Elementes 1 ..USB-interface 2 ..Charging socket 3 ..ALGE multiport 4 ..Connection for displayboard 5 ..Connection for start emitter (C0) 6 ..Connection for finish emitter (C1) 7 ..Standard ALGE photocell socket Gerneral The program jumping is a program to do certain training test with jumping.
- Page 5 Manual TIMY2 – Jumping Select Program Jumping The Timy program "JUMPING" measures the height of the jump when using a contact mat. The contact mat is connected to channel 0 (C0) of at the Timy. • Connect the contact mat at the Timy (channel C0) •...
- Page 6 Manual TIMY2 – Jumping 4.2 Counter Movement Jump The counter movement jump is used in sports science for jump analysis. It helps to test the ability of concentric force jump muscles (a backswing (down) is allowed). The measurement is the same as for Squat Jump, but the movement of the athlete is different.
- Page 7 Manual TIMY2 – Jumping Interface for display board Output format: 1 start-bit, 8 data-bit, no parity-bit, 1 stop-bit factory setting: 9600 baud (necessary for ALGE GAZ display board) Bit rate: 2400, 4800, 9600, 19200, 28800, 38400 Transmission protocol: ASCII Each lane ends with a carriage return (CR)
- Page 8 Manual TIMY2 – Jumping Subject to changes Copyright by: ALGE-TIMING GmbH Rotkreuzstr. 39 6890 Lustenau / Austria https://www.alge-timing.com/ Page 8...
