ALGE-Timing TDC8001 Manual page 50

LED-Brightness
When using LED-display boards from ALGE-TIMING you can adjust the brightness of the LED in 10
levels. The value 0 is relatively dark (e.g. when using it at night), the value 9 is the brightest (e.g. when
you have sunshine).
Menu 55: LED-BRIGHTNESS = 9
Save with: ENTER
Displaytime to next StNo
After the start the bib will stay for the duration of the adjusted time before it changes to the next bib (only
when using Automatic bib counting on UP or DOWN. This is important to avoid in case of double im-
pulses that the next bib start by accident.
Menu 56: DISPLAYTIME TO NEXT STNO = 3
Save with: ENTER
Add PTO Immediately
The PTO is a penalty time that in show jumping that a competitor can get if the horse refuses to jump a barrier
but the barrier drops. If you ADD PTO IMMEDIATELY, then it adds this penalty time already to the running time.
Latching Blockkeys
Is used for show jumping and agility. When you select LATCHING BLOCKKEYS = ON, than you do not have to block
permanent the block key for start and finish to avoid wrong timing impulses. If you press once on the BLOCK key
you can activate the start or finish. When using the next bib the "Block-Mode" again active.
This menu has also a second selection with PRINT BLOCKTIMES. If you have this on ON it will print and store the
time of day of "blocked" impulses (but the time will not stop).
Menu 58: LATCHING BLOCKKEYS = OFF
PRINT BLOCKTIMES
Change: YES/NO Save with: ENTER
Pulse from Radio
When receiving impulses by radio (e.g. WTN or TED) it is possible to activate by selection <YES> for
the channel that the time delay cause by the radio transmission (0.1 sec.) will be automatically corrected.
Menu 59: Pulse from Radio: Channel 0 = YES<
Save with: ENTER
Attention: Until version 13.31 this menu was called „Impulse from TED".
Startnumber-Info RS232
If this menu is active it will output two information through RS232 and RS485 when you input the bib for the
start. As soon as you start to input a number it will output s0000. When you confirm the new bib with <ENTER>
it will output sXXXX (XXXX = bib). The same happens at the input of a finish bib with n0000 and nXXXX.
When you use a mode that switches the bibs automatically it outputs only nXXXX or sXXXX.
This information about the bib goes also through the RS232 interface on channel 2.
Manual
TdC 8001
Menu 55
Menu 56
Menu 57
Menu 58
= ON
Input ON or OFF
Menu 59
Channel 1 = NO
Channel 2 = NO
Channel 3 = NO
Menu 60
-50-
Default = 9
Input: 0 to 9
exit with <ENTER>
Default = 3 seconds
Input 0 to 9 seconds
exit with <ENTER>
Default = OFF
Default = OFF
Input ON or OFF
exit with <ENTER>
Default = all OFF
Channel 0 is switched on
Channel 1 is switched off
Channel 2 is switched off
Channel 3 is switched off
Default = OFF
