Next Syncimpulse
This function allows you to synchronize other timing devices with this TdC8001 (that is already running). When
you select this menu, it will output at the next full minute a sync impulse through channel 0 (C0). In order to sync
another timing device, start it and input the time of the next full minute and connect it through channel C0.
Extern Beep
You can select that through the channels with YES that you want to have a beep output through an external
speaker connected at socket (f).
RS485 User
You can select the adjustment of the interface RS485. When using the WTN (Wireless Timing Network), it will
read delayed transmitted timing impulses and report a continuous blocked WTN channel.
If you select the display board mode you have to select between three baud rates (2400, 9600, 19200)
Menu 63: RS485 USER
Save with: ENTER
Last Impulse Validity
For special timing use, e.g. when you have a team and the last impulse of a team member should be shown. If
you input a time between 0.00 and 9.99 seconds it will not take the first impulse, but the impulse that has no
other impulse during the time adjusted. If you adjust 0.00 seconds this function is not activated.
Manual
TdC 8001
Menu 61
Menu 62
Menu 63
Wireless TN<
DB 2400 Bd
DB 9600 Bd
DB 19200 Bd
Menu 64
-51-
Default = OFF
Default = OFF
WTN connected
Display Board with 2400 Baud
Display Board with 9600 Baud
Display Board with 19200 Baud
Default = 0.00 seconds
