ALGE-Timing TDC8001 Manual page 92

<STOP>:
<MEMO>:
<INPUT>:
<CLEAR> during race:
<CLEAR> during MEMO:
<CLEAR> during Menu:
<ALT> and <CLEAR>:
<ALT> and <ENTER>:
<CLASS>:
<ALT> and <CLASS>:
<*>:
<F4>:
Channel assignment
c0 = start channel
c1 = finish for inside lane
c2 = no function
c3 = no function
c4 = finish for outside lane
Default main menu:
Menu 1: delay time start
Menu 2: delay time finish
Menu 4: display time 1
Menu 16: paperfeed
Menu 17: RS232 baud rate
Menu 19: d-board baud rate
Menu 21: beep
Menu 25: change race
Menu 26: d-board test
Menu 53: start number stepping
Menu 55: LED-brightness
Menu 59: pulse from radio
Menu 62: extern beep
Menu 63: RS485 user
Printer: example of printout
0018 ST 10:00:00.1000
0023 C1 10:00:00.1000
0018 200m
0023 200m
0023 600m
0018 600m
0023 FT 10:00:54.7567
0023 1000m
0018 FT 10:00:54.9731
0018 1000m
Manual
TdC 8001
manual stop impulse for outside lane
times are stored and can later be assigned with <INPUT> to the cor-
rect competitor
time stored with <MEMO> can be assigned to the competitors - IN-
PUT of keypad (12) for inside and INPUT of keypad (8) for outside
the last time of competitor (inside or outside) is cleared
time marked with cursor is cleared
the last time of competitor (inside or outside) is cleared
last cleared time of this competitor is restored, only possible as long
as competitor did not receive new time
input that competitor gave up (e. g. fall)
print current ranking
print ranking on RS232 interface
output all times on RS232 interface
to select new race or change to existing race (only active when start
number can be entered)
= 1.0 sec.
= 0.3 sec.
= 3 sec.
= 0
= 9600 baud
= 2400 baud
= on
= upwards
= 9
= alle Kanäle aus
= alle Kanäle aus
= Wireless TN (WTN)
start time start number 18
start time start number 23
intermediate time start no 18 at 200 m
00:15:1287
intermediate time start no 23 at 200 m
00:15.2841
intermediate time start no 23 at 600 m
00:35.4567
00:35.8714 intermediate time start no 18 at 600 m
finish time start no 23
00:54.6567 run time start no 23 (1000 m)
finish time start no 18
00:54.8731 run time start no 18 (1000 m)
-92-
c5 = no function
c6 = no function
c7 = no function
c8 = no function
c9 = no function
