− display (1) must show correct start number (and group)
start impulse for number 1 effected
−
display (5) now shows running time, display (6) the started start number
−
− display (1) changes automatically to next start number
when the competitor triggers the finish photocell, the running time is displayed; the time of day
−
is printed with run time and speed
start impulse for number 2 effected
−
− display (5) now shows running time, display (6) started start number
display (1) changes automatically to next start number
−
when the competitor triggers the finish photocell, the rinning time is displayed; time of day is
−
printed with run time and speed
etc.
−
When start number automatic is set to START, only one competitor must be on the course.
Channel assignment
c0 = start channel
c1 = finish channel
c2 = no function
c3 = no function
c4 = no function
Default main menu:
Menu 1: delay time start
Menu 2: delay time finish
Menu 3: seconds mode
Menu 4: display time 1
Menu 6: display thousandths
Menu 7: info display
Menu 9: running tenth
Menu 11: run time rank
Menu 12: start number automatic
Menu 13: automatic time
Menu 14: print start time
Menu 16: paperfeed
Menu 17: RS232 baud rate
Menu 18: RS232 run time
Menu 19: d-board baud rate
Menu 20: d-board channel 2
Menu 21: beep
Menu 23: groups
Menu 25: change race
Menu 26: d-board test
Menü 32: distance
Menu 53: bib-counting
Menu 55: LED-brightness
Menu 56: delaytime to next StNo
Menu 59: pulse from radio
Menu 62: extern beep
Menu 63: RS485 user
Printer: example of printout
0001 ST 11:47:59.9965
FT 11:48:02.0775
RT
SP km/h
0002 ST 11:48.07.1017
FT 11:48.09.2666
RT
SP km/h
Manual
TdC 8001
c5
c6
c7
c8
c9
= 1.0 sec.
= 0.3 sec.
= off
= 3 sec.
= off
= finish
= off
= on
= off
= 00:00:00.00
= off
= 0
= 9600 baud
= off
= 2400 baud
= running
= on
= off
= 100 m
= manual
= 9
= 3
= all channels off
= all channels off
= Wireless TN (WTN)
start time (1
finish time (2
0:02.081 run time
172.99 speed in km/h
start time (1
finish time (2
0:02.165 run time
166.28 speed in km/h
-78-
= no function
= no function
= no function
= no function
= no function
photocell)
st
photocell)
nd
photocell)
st
photocell)
nd
