ALGE-Timing TDC8001 Manual page 42

Display Time 2:
Period of time that indicates for how lond the second time in the second heat (total or run time) is shown
on display (5) and the scoreboard before the ranking disappears (or back to total time).
Menu 5: DISPLAY TIME 2 = 03 s
Save with: ENTER
Display Thousandth
Usually the 1/1000 seconds are not shown on the display. If they are, the time display is shifted two
digits to the left. No hours can be shown anymore. The thousandth can only be displayed if precision is
set to thousandth.
Menu 6: DISPLAY THOUSANDTH
Save with: ENTER
Infodisplay
Different displays can be set on the info display (7) during the timing.
Menu 7: INFO-DISPLAY
Save with: ENTER
Start: The info display always show the running times. This display only works in the program
−
SPLIT for individual starts.
<F1> first time started
−
<F2> current time, last stopped time in first line of info display (7)
−
− <F3> last time started
Finish: The info display always shows the finish times. This display works for all start modes in
−
program SPLIT.
<F1> first time with stop impulse (intermediate or finish time)
−
− <F2> current time, last stopped time in first line of info display (7)
<F3> last time with stop impulse, fourth line of info display (7)
−
Off: No times are shown in info display (7).
−
Running Time
You can choose if the time starts at 0:00.00 or at total time in second and following heats.
e. g.: run time of 1 heat of start number 5 is 1:30.45
st
RUN: time starts in 2
TOTAL: time starts in 2
Menu 8: RUNNING TIME
Save with: ENTER
Running Tenth
Display (5) and interface "Display Board" (e) can output running 1/10 seconds (the scoreboard cannot
display 1/10 seconds). The running 1/10 is important if a video generator (TV) must be supplied. The
display board GAZ is not able to show a running 10
Menu 9: RUNNING TENTH
Save with: ENTER
Manual
TdC 8001
Menu 5
Menu 6
ON
OFF<
Menu 7
START<
FINISH
OFF
Menu 8
heat at 0:00.00, run time is shown in the finish
nd
heat at 1:30.45, total time is shown in the finish
nd
RUN<
TOTAL
Menu 9
th
ON
OFF<
-42-
Default = 03s
input seconds with finish keypad (8)
save time with <ENTER>
Default = OFF
F1 display 1/1000 sec
F2 display 1/100 sec
confirm selection with <ENTER>
Default = START
F1 display is start oriented
F2 display is finish oriented
F3 no display
confirm selection with <ENTER>
Default = RUN
F1 run time is displayed
F2 total time is displayed
confirm selection with <ENTER>
Default = AUS
.
F1 running 1/10 activated
F2 running 1/10 deactivated
confirm selection with <ENTER>
