− at next full minute a start impulse is issued via c0
TdC 8001 is ready for timing
−
press <F2> if display (5) shows a wrong time of day
−
− enter time with finish keypad (8) and confirm with <ENTER>
start clock with start signal (<START> or channel c0)
−
Race procedure:
enter * and + on keypad (9) middle segment on display (1) is at top
−
enter number of heat for start with start keypad (12) and <ENTER>
−
− display (1) must show correct heat number (and group)
enter heat number for finish with finish keypad (8) and <ENTER>
−
− display (6) must show correct heat number (and group)
start impulse for heat 1 effected (from channel c0)
−
display (1) changes automatically to next start number
−
− display (5) shows running time
impulse c1 for lane 1 effected
−
− impulse c4 for lane 2 effected
impulse c7 for lane 3 effected
−
− impulse c2 for lane 4 effected
All times are displayed one underneath the other in the info display (5) (if info display is set to finish
(menu 7)). For every lane any number of impulses can be received. The time is always shown on the
display and the display board for the time set in "display time 2". The "display time 2" start anew with
every impulse. If set to zero, the time stops until a new impulse arrives or until it is set to a new heat.
Key functions
clear start time
restore last cleared start time
clear finish time c1
restore last cleared finish time c1
block start time
ignore start time
block finish time c1
ignore finish time c1
edit start times
edit finish times
Channel assignment
c0 = start channel
c1 = finish channel
c2 = finish channel
c3 = finish channel
c4 = finish channel
Default main menu:
Menu 1: delay time start
Menu 2: delay time finish
Menu 3: seconds mode
Menu 4: display time 1
Menu 5: display time 2
Menu 6: display thousandth
Menu 7: info display
Menu 9: running tenth
Menu 11: run time rank
Manual
TdC 8001
Keypad (12) or (9)
CLEAR
ALT + CLEAR
BLOCK
ALT + BLOCK
INPUT
c5 = finish channel
c6 = finish channel
c7 = finish channel
c8 = finish channel
c9 = finish channel
= 1.0 sec.
= 0.3 sec.
= off
= 3 sec.
= 3 sec.
= off
= finish
= off
= on
-87-
Keypad (8) or (9)
CLEAR
ALT + CLEAR
BLOCK
ALT + BLOCK
INPUT
