Setup
Connection Specifications
3.4.5
Best practice
• Differential signals offer good resistance against electrical interference. Therefore, we recommend
using a differential scheme. Nevertheless, the controller supports both schemes – differential and
single-ended (unsymmetrical).
• For best performance, we strongly recommend using encoders with a line driver. Otherwise, lim-
itations may apply due to slow switching edges.
• Even though 2-channel will do, we strongly recommend to use only 3-channel versions.
Module
Header Pin
A30...A36
Table 3-44
Sensor supply voltage (V
Max. encoder supply current
Min. differential input voltage
Max. input voltage
Line receiver (internal)
Max. input frequency
Continued on next page.
3-44

Encoder

Compact/CB
Connector
Pin
X5 | 3
A40 X5 | 2
A41 X5 | 6
A42 X5 | 5
A43 X5 | 8
A44 X5 | 7
A45 X5 | 10
A46 X5 | 9
Encoder – Pin assignment
)
Sensor
Document ID: rel6627
Edition: November 2016
© 2016 maxon motor. Subject to change without prior notice.
Signal
GND Ground
V Sensor supply voltage (+5 VDC; I
Sensor
Channel A Digital incremental encoder channel A
Digital incremental encoder channel A
Channel A\
complement
Channel B Digital incremental encoder channel B
Digital incremental encoder channel B
Channel B\
complement
Channel I Digital incremental encoder channel I
Digital incremental encoder channel I
Channel I\
complement
Encoder (differential)
+5 VDC
70 mA
±200 mV
±12 VDC
EIA RS422 standard
6.25 MHz
EPOS4 Module/Compact 24/1.5 Hardware Reference
Description
≤100 mA)
L
