Limitations; Dimensional Drawings; Figure 2-4 Power Dissipation And Efficiency; Figure 2-5 Epos4 Module 24/1.5 - Dimensional Drawing [Mm] - maxon motor EPOS4 Module 24/1.5 Hardware Reference Manual

Specifications

Limitations

2.2.2
Figure 2-4
2.3 Limitations
Table 2-5
2.4

Dimensional Drawings

Figure 2-5
2-14
Power Dissipation and Efficiency
Power dissipation and efficiency
Protection functionality
Undervoltage
Overvoltage
Overcurrent
Thermal overload
Limitations
EPOS4 Module 24/1.5 – Dimensional drawing [mm]
Edition: November 2016
© 2016 maxon motor. Subject to change without prior notice.
Switch-off threshold
8.0 V
28 V
6 A
100 °C
Document ID: rel6627
EPOS4 Module/Compact 24/1.5 Hardware Reference
Recovery threshold
8.5 V
27.5 V
—
90 °C
maxon motor control
EPOS4 Positioning Controller
