Connections

Encoder Connection

4.6 Encoder Connection
Best Practice
The use of encoder with built-in line driver is mandatory.
Even though 2-channel will do, we strongly recommend to use only 3-channel versions!
By default, the controller is set for a 500 count per turn encoder. For other encoders, you will need to
adjust respective settings via software.
Encoder supply voltage
Max. encoder supply current
Min. differential Input voltage
Line receiver (internal)
Max. encoder input frequency
Figure 4-9
Pin
A10
A11
A12
A13
A14
A15
A16
A17
4-24
Encoder Input Circuit
Signal
+V
aux
GND
Channel A
Channel A\
Channel B
Channel B\
Channel I
Channel I\
Document ID: rel7050
Edition: May 2017
© 2017 maxon motor. Subject to change without prior notice.
+5 VDC
100 mA
± 200 mV
EIA RS422 Standard
5 MHz
Description
Auxiliary output voltage for Hall sensors and encoder +5 VDC
Ground of Hall sensor/encoder supply
Channel A
Channel A complement
Channel B
Channel B complement
Index
Index complement
EPOS2 Module 36/2 Hardware Reference
maxon motor control
EPOS2 Positioning Controller
