Table 3-18 Encoder Cable - maxon motor EPOS4 Module 24/1.5 Hardware Reference Manual

Setup
Pin Assignment for Connector Boards & Compact Versions
Cross-section
Length
Head A
Head B
Table 3-18
3-28
Encoder Cable (275934)
10 x AWG28, round-jacket, twisted pair flat cable, pitch 1.27 mm, grey
3.2 m
DIN 41651 female, pitch 2.54 mm, 10 poles, with strain relief
DIN 41651 plug, pitch 2.54 mm, 10 poles, with strain relief
Encoder Cable
Document ID: rel6627
Edition: November 2016
