maxon motor control
EPOS2 Positioning Controller
Hardware Reference
Edition November 2017
Positioning Controller
Hardware Reference
Document ID: rel7748
maxon motor ag Brünigstrasse 220 P.O.Box 263 CH-6072 Sachseln Phone +41 41 666 15 00 Fax +41 41 666 16 50 www.maxonmotor.com
