FACTORY-INSTALLED OPTIONS
AMBIENT AIR TEMPERATURE SENSOR
SERVICE
REMOVAL
1. Depress two tabs on top of grille, then tip forward.
2. Disconnect the main chassis connector from front
camera connector and remove the grille
3. In right front wheel well, disconnect ambient air
temperature sensor connector
on main chassis harness.
NOTICE
Front fascia hidden for clarity.
Chassis structure may vary slightly from that shown.
13.62
q
w
from connector
4. Carefully cut the ziptie portion of the edge clip
securing the ambient air temperature sensor harness.
5. Carefully remove the ambient air temperature sensor
harness by pulling harness up along the regulator
harness and through slot in RH side of radiator
shroud.
INSTALLATION
1. In right front wheel well, join ambient air temperature
q
sensor connector
to connector
harness.
NOTICE
Front fascia hidden for clarity.
Chassis structure may vary slightly from that shown.
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
e
w
on main chassis
© Copyright Polaris Inc.
